DVR8H2
V. 02 – 07/01/2014
4
©Velleman nv
4.
Features
H.264 real-time compression format
high resolution recording:
o
CIF: 352 x 288 pixels @ 200 IPS (PAL)
o
frame: 704 x 576 pixels @ 100 IPS (PAL)
full D1 (or Frame) at real-time recording on 4 channels
recording size and IPS customisable per channel (within maximal recording capacity). Some examples:
o
8 channels frame recording at 12.5 IPS
o
2 channels frame recording at 25 IPS (full frame) + 6 channels frame recording at 6 IPS
o
2 channels frame recording at 25 IPS (full frame) + 2 channels frame recording at 12.5 IPS +
4 channels frame recording at 6 IPS
o
...
multiplex: allows live display, recording, playback, backup and network operation
automatic integrated Dynamic Domain Name Service (DDNS): free service
backup function: supports USB 2.0 flash drive and network backup
powerful mobile surveillance support on all major platforms including iPad, iPhone, BlackBerry, Windows
Mobile, Symbian and Android – EagleEyes software
push video function with iPad, iPhone, Android smart phone, and tablet
o
the DVR instantaneously sends video images from channel 1 to the activated mobile device when the
alarm is triggered
o
the DVR also sends push messages when there is a problem with the system
intelligent motion trigger recording:
o
advanced motion detection
o
scheduled motion detection recording (with 3 adjustable parameters)
system auto recovery after power reconnected
supports daylight-saving function
supports manual / timer / motion / alarm recording functions
multi-language OSD: English, French, Dutch, German, Portuguese, Spanish, Czech, Hungarian, Greek,
Chinese and Vietnamese
user manual: English
quick start manual: English, Dutch, French, Spanish, German
optional hard disks (not incl.): 500 GB (HD500GB/S), 1 TB (HD1B/S) or 2 TB (HD2TB/S)
IR remote control: DVRRC4 (incl.)
optional monitor (not incl.): MONSCA4, MONSCA5, MONSCA7
optional router (not incl.): EM4542, EM4553, EM4570.
5.
Overview
Refer to the illustrations on page 2 of this manual.
Front panel
LED
indicators
HDD is reading or recording.
DVR is powered on.
NAVIGATE
Press one of the four positions on the navigate button to move the cursor
up (
), down (
), left (
) or right (
).
In playback mode, press the buttons to play/pause (
), stop (
),
fast rewind (
) or fast forward (
).
In setting mode, press the up (
) or down (
) button to change the
setting in the menu.
MENU
Press MENU to enter the main menu.
ENTER
Press ENTER to confirm the setting.
LIST
Press to quickly search the recorded files by event lists: RECORD / MOTION / ALARM / TIME, or
select FULL to show all the event logs.
To quickly search the time you want, select QUICK SEARCH. For more details, refer to the full
user manual.
