KNS6 VELLEMAN

1

KNS6 – TRAINMECH

1. Introduction

&

Characteristics


Thank you for buying the KNS6 ! Read this manual carefully before bringing the KNS6 into use.


• Familiarise yourself with the operation of transmissions steered through gears or pulleys.

• Easy to build, no glue or soldering required.

• Dislodge the pre-cut pieces when you need them and not before. Sand the jagged edges before use (sandpaper

included)

• The kit is powered by 2 AA-batteries (not included).


The kits of the KNS-series are supplied with prepunched boards, a gearbox, gears, shafts, a switch, a motor, a
battery holder and all necessary parts.

Note that the figures with the assembly instructions can be found in the second folder “KNS6 – Figures”!!!

2. Parts List

Part

Quant. Description Part

n° Quant. Description

1

1 gearbox 17

2

pulley (15 x 1.9mm)

2

1 battery

holder 18

2

nylon post (H = 6mm)

3

1 motor

DC

6V 19

8

nylon post (H = 3mm)

4

1

slide switch with wire

20

3

PVC tube (15 x 1.5mm)

5

1

metal shaft (2 x 40mm)

21

8 nut

M3

6

1

metal shaft (3 x 52mm)

22

4

screw (3 x 12mm)

7

5

metal shaft (2 x 60mm)

23

2

screw (3 x 16mm)

8

1

pinion gear 10T (white)

24

2

screw (3 x 20mm)

9

1

face gear (36T/14T)

25

8

washer (3.2 x 10 x 0.5mm)

10

1 gear

36T/0T 26

32

self-tapping screw (2 x 4mm)

11

1 gear

(36T/14T) 27

2

self-tapping screw (2 x 6mm)

12

1 gear

(36T/14T) 28

10

nylon pad (5.6 x 4.8 x 1.95mm)

13

1

wire with terminal (yellow)

29

10 nylon

pad

(Ø8mm)

14

1

wire with terminal (green)

30

10

nylon pad (6.6 x 4.8 x 2.1mm)

15

2

belt (40 x 1.2mm)

31

8

nylon connector (N-shaped)

16

2

pulley (15 x 2.9mm)

32

13

fixing plate (L-shaped)


3. Prepunched Boards (see KNS6 – Figures

)


4. Assembly (see also KNS6 – Figures

)


Fig. 3 : The gears (n°9/10/11/12) should be placed to the left of the pinion gear (n°8). Note that the protruding

edge should point towards the metal case.


Fig. 4 : Screw 1 x piece n°32 on boards 1 & 2 and attach them to boards n°3 & 4.
