LX101
V. 01 – 06/06/2012
8
©Velleman nv
channel function
from to description
white
201 205
3200K
206 210
3400K
211 215
4200K
216 220
4900K
221 225
5600K
226 230
5900K
231 235
6500K
236 240
7200K
241 245
8000K
246 250
8500K
251 255
10
000K
6 strobe
000 009
strobe
off
010
255 strobe 0 ~ 20Hz (slow ~ fast)
7 auto
programs
000 051
no
function
052
101 auto program 1
102
152 auto program 2
153
203 auto program 3
204
254 auto program 4
255
-
auto program 5
8
speed
000
255 speed of auto programs (slow ~ fast)
9 dimmer
000
051 default dimmer speed
052 101
linear
dimmer
102 152
non-linear
dimmer
1
153 203
non-linear
dimmer
2
204 255
non-linear
dimmer
3
4-Channel Mode
channel function
from to description
1 master
dimmer
000
255
0 ~ 100%
2
red
000
255
0 ~ 100%
3
green
000
255
0 ~ 100%
4
blue
000
255
0 ~ 100%
3-Channel Mode
channel function
from to description
1
red
000
255
0 ~ 100%
2
green
000
255
0 ~ 100%
3
blue
000
255
0 ~ 100%
7.5
Master/Slave Mode
This mode allows control several units simultaneously.
1. Use standard DMX cables to daisy-chain your units together via the DMX connector on the rear of
each fixture. For longer cable runs we suggest using a terminator on the last fixture.
2. Choose the first unit in the chain to function as the master fixture. Press
