Velleman HPG1 User Manual
Page 6
- 6 -
Survey of the connections and controls
1) Signal and menu display
2) Menu button / menu selection up
3) Up and Down set buttons
4) Settings menu / menu selection down
5) Output level indicator
6) On/Off
switch
7) DC input (9V/200mA)
8) BNC output connector
9) Charge LED: Will light when the batteries are being charged
10) Only for service
3
3
4
2
1
5
10
9
8
7
6
