Velleman HPG1 User Manual
Page 18
- 18 -
Übersicht der Anschlüsse und Bedienungs-elemente am Gerät
1) Signal- und Menü-Anzeige
2) MENU-Taste / Auswahl Submenü UP
3) "Up/Down"-Taste
4) Einstellungen / Auswahl Submenü DOWN
5) Niveau des Ausgangssignals
5) Ein/Aus-Schalter
6) Adapteranschluss (9VDC/200mA)
8) BNC-Ausgangsanschluss
9) "Laden" LED-anzeige : vorne am Gerät leuchtet wenn die
Batterien geladen werden
10) Wartungspunkt
3
3
4
2
1
5
10
9
8
7
6
