Channel
Value
Function
from to
10
0
255
pan position - fine
11
0
255
tilt position - fine
12
0
255
pan-tilt speed, slow -> fast
13
0
255
pan-tilt macro, fast -> slow
14*
0 7
no
function
8
15
pan-tilt move 3 seconds blackout
16
23
cancel pan-tilt move 3 seconds blackout
24
31
Colour wheel move while blackout
32
39
cancel colour wheel move while blackout
40
47
Gobo wheel move while blackout
48
55
cancel gobo wheel move while blackout
56
63
Gobo wheel rotate while blackout
64
71
cancel gobo wheel rotate while blackout
72
79
Prism move while blackout
80
87
cancel prism move while blackout
88
95
cancel all moving
96 103
pan
reset
104 111
tilt
reset
112 119
Colour
wheel
reset
120
127
Gobo wheel reset
128
135
Gobo rotating reset
136
143
Prism reset
144 151
Focus
reset
152 159
Total
reset
160 255
no
function
* only when in non-rotating colour and gobo mode
7.
Cleaning and maintenance
•
All screws should be tightened and free of corrosion.
•
The housing, the lenses, the mounting supports and the installation location (e.g. ceiling, suspension,
trussing) should not be deformed, modified or tampered with e.g. do not drill extra holes in mounting
supports, do not change the location of the connections…
•
Mechanically moving parts must not show any signs of wear and tear.
•
The electric power supply cables must not show any damage. Have a qualified technician maintain the
device.
•
Disconnect the device from the mains prior to maintenance activities.
•
Wipe the device regularly with a moist, lint-free cloth. Do not use alcohol or solvents.
•
There are no user-serviceable parts, apart from the fuse.
•
Contact your dealer for spare parts if necessary.
8.
Technical specifications
VDPL601MHB14 VDPL601MHS14
power supply
230Vac / 50Hz
LED
Luminus (USA) high power
gobo size
24.9mm (1”)
power consumption
90W
dimensions
278 x 278 x 490mm
(10.95” x 10.95” x 19.29”)
275 x 278 x 335mm
(10.83” x 10.95” x 13.19”)
weight
14kg (30.86lb)
12kg (26.46lb)
fuse
2A / 230VAC (FF2N)
