5 Start address 1 6 (1 + 5) 11 (6 + 5) 508
Channel 1~5 6~10 11~15
10 Start address 1 11 (1 + 10) 21 (11 + 10) 503
Channel 1~10 11~20 21~30
To set the device to work with a DMX controller:
1. Press until is displayed and press .
2. Use and to select the appropriate channel DMX mode and press .
3. Press until is displayed and press .
4. Use and to set the DMX starting address (A001-A512) and press .
DMX Channel Values
10 channel mode
channel
value function
1 000-255 master dimmer 0% ~ 100%
2 000-255 red 0% ~ 100%
3 000-255 green 0% ~ 100%
4 000-255 blue 0% ~ 100%
5 000-255 white 0% ~ 100%
6 000-010 no function
011-030 R 100% + G 0%~100%
031-050 R 100% ~ 0% + G 100%
051-070 G 100% + B 0~100%
071-090 G 100% ~ 0% + B 100%
091-110 R 0% ~100% + B 100%
111-130 R 100% + B 100%~ 0%
131-150 R 100% + G 0% ~100% + B 0% ~100%
151-170 R 100% ~ 0% + G 100% ~ 0% + B 100%
171-200 R 100% + G 100% + B 100% + W 100%
201-205 colour temperature 1 warm
206-210 colour temperature 2
211-215 colour temperature 3
216-220 colour temperature 4
221-225 colour temperature 5
226-230 colour temperature 6
231-235 colour temperature 7
236-240 colour temperature 8
241-245 colour temperature 9
246-250 colour temperature 10
251-255 colour temperature 11 cold
7 000-009 no function
010-255 strobe (slow ~ fast)
000-051 no function
052-101 built-in program p1
8 102-152 built-in program p2
153-203 built-in program p3
204-254 built-in program p4
