VDPLOP1810RGBW
V. 01 – 22/07/2013 6 ©Velleman nv
Button Function
scrolls through the menu options in ascending order
scrolls through the menu options in descending order
used to select and store the current menu or option within the menu
• The control panel display shows the menu items you select from the menu map. When a menu
function is selected, the display will show immediately the first available option for the selected menu
function. To select a menu item, press .
• Use the and buttons to navigate the menu map and menu options. Press
to access the menu function currently displayed or to enable a menu option. To return to the
previous option or menu without changing the value, press the button.
The menu contains the following items:
Menu
Submenu Options Notes
C-- C-01 red
static colour C-02 green
C-03 blue
C-04 white
C-05 green + blue
C-06 red + blue
C-07 red + green
C-08 red + green + blue
C-09 red + white
C-10 green + white
C-11 blue + white
C-12 red + green + white
C-13 red + blue + white
C-14 green + blue + white
C-15 red + green + blue +
white
U-- R 0~255 red 0% ~ 100%
(user mode to set colours) G 0~255 green 0% ~ 100%
B 0~255 blue 0% ~ 100%
W 0~255 white 0% ~ 100%
S 0~20 strobe speed (slow ~
fast)
P-- P1 s 000 ~ 100 15 colours fade
0% -100%-0%
(built-in programs) P2 s 000 ~ 100 15 colours fade
0% -100%
P3 s 000 ~ 100 15 colours fade 100%-
0%
P4 s 000 ~ 100 macro fading
P5 s 000 ~ 100 loop of above programs
1 to 4
ADDR D1 ~ D512 dmx addressing
PERS 10CH 10 channel dmx mode
5-CH 5 channel dmx mode
4-CH 4 channel dmx mode
DIM OFF dimmer speed off
(dimmer speed) DIM1 dimmer speed 1
DIM2 dimmer speed 2
DIM3 dimmer speed 3
