VDPLP64SL
10.01.2011
©Velleman nv
7
•
Press
•
Use
•
Press
DMX Channel Values
3-Channel Mode
channel function from
to
description
1
red
000
255
dimmer 0 ~ 100%
2
green
000
255
dimmer 0 ~ 100%
3
blue
000
255
dimmer 0 ~ 100%
7-Channel Mode
channel function from
to
description
1
red
000
255
dimmer 0 ~ 100%
2
green
000
255
dimmer 0 ~ 100%
3
blue
000
255
dimmer 0 ~ 100%
4 colour
macros
000 015
no
function
016 255
colour
macros
5
speed
(channel 6 @ 032 ~ 223)
000
255
slow ~ fast
strobe
(channels 1 ~ 4 only)
000 015
no
function
016
255
slow ~ fast (6 Hz ~ 18 Hz)
6
mode
(channel 5 controls speed
when channel 6 = 032 ~
223)
000 031
RGB
032
063
pulse 0 ~ 100% with RGB faders
064
095
pulse 100 ~ 0% with RGB faders
096
127 pulse 100 ~ 0 ~ 100% with RGB faders
128 159
auto
fade
160
191
auto switch (3 colours)
192
223
auto switch (7 colours)
224 255
sound
control
7
dimmer
000
255
dimmer 0 ~ 100%
8. Cleaning and maintenance
•
All screws should be tight and free of corrosion.
•
The housing, the lenses, the mounting supports and the installation location (e.g. ceiling, suspension,
trussing) should not be deformed, modified or tampered with e.g. do not drill extra holes in mounting
supports, do not change the location of the connections …
•
Mechanically moving parts must not show any signs of wear and tear.
•
The electric power supply cables must not show any damage. Have a qualified technician maintain
the device.
•
Regularly remove dust from the housing and the air vents using a slightly damp cloth.
•
There are no user-serviceable parts inside. Refer to an authorized dealer for service and/or spare
parts.
Fuse Replacement
•
Wedge the fuse holder out of its housing with a flat-head screwdriver.
•
Remove the damaged fuse from its holder and replace with exact same type of fuse.
•
Insert the fuse holder back in its place and reconnect power.
9. Troubleshooting
problem possible
solution
fuse keeps blowing
check total load placed on fixture
chase is too slow
check user manual for speed adjustment
fixture has no power
check for power on mains
check fixture’s fuse
fixture is not responding
check DMX settings for correct addressing
check DMX cables
check polarity switch settings
check DMX indicator on LCD display
