number of fixtures on a serial data link is 32 fixtures.
•
A DMX terminator is recommended for installations where the DMX cable has to run a long distance
or is in an electrically noisy environment (e.g. discos). The terminator prevents corruption of the
digital control signal by electrical noise. The DMX terminator is simply an XLR plug with a 120Ω
resistor between pins 2 and 3, which is then plugged into the XLR output socket of the last device
in the chain.
c) general
•
Make sure there is no flammable material within a 50cm radius of the device and there is sufficient
cooling.
•
Have a qualified electrician carry out the electrical connection.
•
Connect the device to the mains with the power plug. All fixtures must be powered directly off a
grounded switched circuit and cannot be run off a rheostat or dimmer circuit, even if the rheostat
or dimmer channel is used solely for 0% to 100% switch.
•
The installation has to be approved by an expert before the device is taken into service.
7. Operation
Refer to the illustrations on page 2 of this manual.
Control Panel Navigation
•
Access the control panel functions using the four panel buttons located directly underneath the LCD
display.
button function
