USER MANUAL
1.
Introduction
Thank you for choosing Velleman! Please read the manual thoroughly before bringing this device into
service. If the device was damaged in transit, do not install or use it and contact your dealer.
2.
Safety Instructions
•
Damage caused by disregard of certain guidelines in this manual is not covered by the warranty
and the dealer will not accept responsibility for any ensuing defects or problems.
•
Damage caused by user modifications to the device is not covered by the warranty.
•
Only use the device for its intended purpose. Using the device in an unauthorised way will void
the warranty.
•
Check the contents prior to assembly. Use proper tools and never use defective or deformed parts
as an improper installation may cause serious injury.
•
Any included hardware is for mounting on solid brick, concrete or hard wood
ceilings/battens. When mounting on wood, do not use any concrete anchors. Do not use any
included hardware for mounting on steel. If uncertain about the nature of the ceiling or mounting
techniques, please consult an expert.
•
Respect the product’s max. load specifications. Protect this device from shocks and abuse and
avoid brute force when operating. Check the installation on a bimonthly basis.
•
An adequate mounting is essential and falls outside the responsibility of Velleman nv. Respect all
installation and operating directions of the device to be mounted/installed.
•
Only use the device at an indoor location, protected from rain, moisture, splashing and dripping
liquids. Make sure the chosen location spot is able to support the weight of the bracket and
device.
•
Keep fingers away from articulations to avoid injury. Keep the device out of reach of children and
unauthorized users at all times.
3.
General Guidelines
Refer to the Velleman® Service and Quality Warranty on the last pages of this manual.
4.
Features
•
support for projector
•
easy installation
•
360° pan and 15° tilt/roll movement
•
comes with all necessary plugs and screws for assembly and mounting
5.
Overview
Refer to the illustrations on pages 2, 3 and 4 of this manual.
projector support
9 bracket adaptor #1
1 ceiling plate
10 bracket adaptor #2
2 projector plate
11 spring washer – M6
3 extension – 15cm
12 hex key – 5mm
4 extension – 8cm
13 hex key – 4mm
5 projector arm
14 lag bolt – 6mm
6 rubber gasket
15 concrete anchor
7 screw – M6
16 flat washer – M6
8 screw – M4
17 bolt with 2 spacers
6.
Installation
P-1) Use the ceiling plate [1] to determine and indicate the position of the mounting holes.
P-1A) When mounting on a brick or concrete ceiling, drill holes size Ø8mm and at least
50mm deep at the indicated positions. Insert the included anchors [15] and mount
the ceiling plate [1] on the ceiling using the 3 included screws [14].
P-1B) When mounting on a wooden ceiling or ceiling batten, drill holes size Ø3mm and at
least 50mm deep at the indicated positions. Make sure all the holes are blind holes.
Mount the ceiling plate [1] on the ceiling using the 3 included screws [14].
Slide the rubber gasket [6] over the ceiling plate [1].
P-2) Mount the projector arms [5] and projector plate [2] on the projector.
P-2A) Fix the projector arms [5] on the projector using the included bolts [17].
