VDPLP56SL
23.07.2010 ©Velleman nv 6
Stand-Alone Mode
Sound-Active Mode
This mode allows a single unit to run to the beat of the music.
• Press
P-- is displayed.
• Press to confirm your selection.
• Use or to select the desired program (p5 ~ p6).
• Press to confirm your selection.
• Use the audio sensitivity knob on the back of the fixture to make the fixture more or less sensitive.
The PAR56 will react to the low frequencies of the music via the internal microphone.
Auto Mode
• Press
P-- is displayed.
• Press to confirm your selection.
• Use or to select the desired program (p1 ~ p4).
• Press to confirm your selection.
Preset Colours
This PAR56 has pre-programmed static colours.
• Press
c-- is displayed.
• Press to confirm your selection.
• Use or to select the desired program (c1 ~ c7).
• Press to confirm your selection.
Custom Static Colours
This PAR56 allows you to create custom static colours.
• Press
u-- is displayed.
• Press to confirm your selection.
• Use or to select the desired colour value (000 ~ 100, from 0 to 100%).
• Press to confirm and to move to the next colour (r, g, b). Set the value for the second and
third colour.
• Finally, press to confirm. Note that you will have selected the first colour. Simply press
Master/Slave Mode
This mode allows control several units simultaneously.
• Use standard DMX cables to daisy-chain your units together via the DMX connector on the rear of
each fixture. For longer cable runs we suggest using a terminator on the last fixture.
• Choose the first unit in the chain to function as the master fixture. Press
mode (p--, c-- or u--).
• Press to confirm your selection.
• On each of the connected slave units, press
• Press to confirm your selection.
• Use or to set the DMX starting address to d001.
DMX Mode
This mode allows you to control the fixture by any universal DMX controller.
• Press
• Press to confirm your selection.
• Use or to set the DMX starting address.
• Press to confirm your selection.
DMX Channel Values
3-Channel Mode
channel function from to description
1 red 000 255 dimmer 0 ~ 100%
2 green 000 255 dimmer 0 ~ 100%
3 blue 000 255 dimmer 0 ~ 100%
