20 320D L Hydraulic Excavator specifications
320D Bucket Specifications and Compatibility
Adapter Capacity* Width Tip Radius Weight Teeth Reach Boom Mass
(w/o tips) Stick Boom
Stick
m 3 yd 3 mm in mm in kg lb Qty R3.9B1 R2.9B1 R2.5B1 M2.4CB2
B Family
General Purpose – K80
0.55 0.72 610 24 1565 61.6 629 1387 3
s s s
—
Capacity K80 0.75 0.98 762 30 1565 61.6 718 1583 4
n s s
—
K80 0.95 1.24 914 36 1565 61.6 790 1742 5
* s s
—
K80 1.17 1.53 1067 42 1565 61.6 852 1878 5
* * n
—
K80 1.39 1.82 1219 48 1565 61.6 926 2041 6
∴ g *
—
K80 1.57 2.05 1372 54 1565 61.6 1000 2205 6
∴ ∴ g
—
Heavy Duty K90 0.47 0.61 610 24 1578 62.1 650 1433 3
s s s
—
K90 0.64 0.84 762 30 1578 62.1 743 1638 4
s s s
—
K90 0.82 1.07 914 36 1578 62.1 813 1792 5
* s s
—
K90 1.00 1.31 1067 42 1578 62.1 866 1909 5
g n s
—
K90 1.19 1.56 1219 48 1578 62.1 956 2108 6
∴ * *
—
K90 1.38 1.80 1372 54 1578 62.1 1030 2271 6
∴ g g
—
Heavy Duty Rock K90 0.54 0.70 610 24 1578 62.1 696 1534 3
s s s
—
K90 0.77 1.00 762 30 1578 62.1 781 1722 4 n s s —
K90 0.84 1.10 914 36 1578 62.1 863 1903 5
* s s
—
K90 1.07 1.40 1067 42 1578 62.1 933 2057 5
g * n
—
Heavy Duty Power K90 0.79 1.03 914 36 1458 57.4 811 1788 5
n s s
—
K90 0.96 1.26 1067 42 1458 57.4 875 1929 5
* n s
—
K90 1.14 1.49 1219 48 1458 57.4 954 2103 6
∴ * n
—
Ditch Cleaning n/a 1.02 1.33 1524 60 1139 44.8 726 1601 0
* s s
—
n/a 1.24 1.62 1830 72 1139 44.8 823 1814 0
g * n
—
CB Family
General Purpose –
K90 0.63 0.82 610 24 1656 65.2 700 1543 3 — — —
s
Capacity K90 0.86 1.12 762 30 1656 65.2 809 1784 4 — — —
s
K90 1.09 1.43 914 36 1656 65.2 903 1992 5 — — —
s
K90 1.34 1.75 1067 42 1656 65.2 977 2153 5 — — —
*
K90 1.58 2.07 1219 48 1656 65.2 1064 2345 6 — — — g
K90 1.83 2.39 1372 54 1656 65.2 1151 2537 7 — — —
∴
Heavy Duty K100 0.53 0.69 610 24 1686 66.4 751 1657 3 — — —
s
K100 0.73 0.95 762 30 1686 66.4 829 1828 3 — — —
s
K100 0.93 1.22 914 36 1686 66.4 944 2080 4 — — —
s
K100 1.14 1.49 1067 42 1686 66.4 1025 2259 5 — — —
n
K100 1.35 1.77 1219 48 1686 66.4 1095 2414 5 — — —
*
K100 1.57 2.05 1372 54 1686 66.4 1181 2604 6 — — —
g
K100 1.78 2.33 1524 60 1686 66.4 1268 2794 7 — — —
∴
K100 1.99 2.60 1676 66 1686 66.4 1340 2954 7 — — —
∴
Heavy Duty Rock K100 0.73 0.95 762 30 1686 66.4 936 2064 3 — — —
s
K100 0.93 1.22 914 36 1686 66.4 1035 2281 4 — — —
s
K100 1.14 1.49 1067 42 1686 66.4 1126 2483 5 — — —
n
K100 1.35 1.77 1219 48 1686 66.4 1211 2670 5 — — —
*
Heavy Duty Power K100 1.12 1.46 1067 42 1592 62.7 1013 2232 5 — — — n
K100 1.33 1.74 1219 48 1592 62.7 1089 2401 5 — — —
*
K100 1.53 2.00 1372 54 1592 62.7 1180 2601 6 — — —
g
Ditch Cleaning n/a 1.25 1.63 1524 60 1262 49.7 739 1629 — — — —
s
n/a 1.53 2.00 1830 72 1262 49.7 837 1845 — — — —
*
s 2100 kg/m 3 (3,500 lb/yd 3 ) max material density
n 1800 kg/m 3 (3,000 lb/yd 3 ) max material density
* 1500 kg/m 3 (2,500 lb/yd 3 ) max material density
g 1200 kg/m
3 (2,000 lb/yd 3 ) max material density
∴ Not Recommended
— Not Available/Recommended
Assumptions for maximum material density rating:
1. Front linkage fully extended at ground line
2. Machine positioned 90 degrees over the side
3. Bucket curled
4. 100% Bucket Fill Factor
Please consult with your Caterpillar dealer personnel for optimum selection of buckets and
work tools that best match your application.
* Based on SAE J296, some calculations of capacity specs fall on borderlines.
Rounding may allow two buckets to have the same English rating, but different metric ratings.
