Working Ranges
All dimensions are approximate.
Meters
Feet
35
11
10
30
9
25
7
8
15
20
4
5
6
3
4
10
3
5
1
2
5
15
10
5
0
0
5
4
3
2
1
1
7
2
6
R3.1 (10'2")
R2.9 (9'6")
R2.6 (8'6")
20
6
25
7
8
11 10
9
8
7
6
5
3
4
8 ft
2
1
0
1
Meters
35
30
25
20
15
10
5
0
Feet
Stick
1 Maximum Digging Depth
2 Maximum Reach at Ground Level
3 Maximum Cutting Height
4 Maximum Loading Height
5 Minimum Loading Height
6 Maximum Depth Cut for 2440 mm (8'0") Level Bottom
7 Maximum Vertical Wall Digging Depth
R3.1
(10'2")
mm (ft)
6590 (21'7")
9260 (30'5")
9210 (30'3")
6570 (21'7")
1810 (5'11")
6400 (21'0")
5400 (17'9")
Reach Booms
5.1 m (16'9")
R2.9
(9'6")
mm (ft)
6390 (21'0")
8990 (29'6")
8880 (29'2")
6270 (20'7")
2000 (6'7")
6160 (20'3")
4910 (16'1")
R2.6
(8'6")
mm (ft)
6090 (20'0")
8780 (28'10")
8920 (29'3")
6280 (20'7")
2300 (7'7")
5870 (19'3")
4930 (16'2")
