Brake and Decel pedal. The D6K features
a single, combined hystat brake and
decel pedal. Two braking configurations
are available through this pedal:
• Transmission braking only: As the
pedal is pressed, the machine will
slow by braking the transmission;
no engine decel will occur.
• Transmission braking and engine
decel: As the pedal is pressed, the
machine will slow by simultaneously
braking the transmission and reducing
the engine speed.
When the pedal is depressed beyond the
detent, the service brakes will be applied.
Bulldozer Control. The blade is
controlled with an ergonomically
designed joystick located to the right of
the operator. This joystick includes a
thumb wheel that controls blade angle.
AccuGrade buttons are conveniently
located on the joystick for quick,
efficient actuation. For non-AccuGrade
equipped machines, a blade shake
button provides aggressive blade
movement for effective removal of
sticky material.
Speed and Direction Control.
The operator controls the speed of the
machine and the direction of travel with
a single joystick control located on the
left console. This joystick includes a
thumb wheel for precise speed control,
as well as a convenient button to store
and recall operator-defined, independent
operating speeds for forward and reverse.
Work Tool Controls. The D6K can be
equipped with either a ripper or a
winch. For maximum flexibility, the
D6K can be configured for ripper
control, winch control, or a selectable
ripper or winch control.
Other cab features. For optimum
operator comfort, the D6K operator
station includes the following
amenities:
• Foot rests for slope work
• Air filter
• Two 12-volt power points
• Storage compartment
• Cup holder
• Dome light
• Rearview mirror
• Coat hook
• Radio ready factory installed
components
• Rear attachment mirror
