302.7D Specifications
Engine Service Refill Capacities Hydraulic System
Engine Model Yanmar 3TNV76 Fuel Tank Capacity 35.2 L 9.3 gal Pump Flow @
Rated Net Power 15.2 kW 20.7 hp Hydraulic Tank 26.5 L 7 gal
2,500 rpm
(ISO 9249) Capacity Operating Pressure –
Gross Power 17.9 kW 24.3 hp
Equipment
Displacement 1115 cm 3 68 in 3
Blade
Operating Pressure –
Travel
Weight
Width 1570 mm 61.9 in
Operating Pressure –
Transport Weight 2670 kg 5,886 lb
with Cab
Transport Weight 2577 kg 5,681 lb
with Canopy
Travel System
Travel Speed
Gradeability
2.1 km/h/
3.8 km/h
30°/58%
1.30 mph/
2.36 mph
Height 290 mm 11.4 in
Dig Depth 419 mm 16.5 in
Lift Height 380 mm 15 in
89.4 23.6
L/min gal
225 bar 3,263 psi
225 bar 3,263 psi
206 bar 2,987 psi
Swing
Auxiliary Circuits
Primary 52.2 L/min
at 225 bar
(13.8 gal/min
at 3,263 psi)
Secondary 30.8 L/min
at 206 bar
(8.1 gal/min
at 2,988 psi)
Maximum Bucket 22.5 kN 5,058 lbf
Force
Maximum Stick Force 15.4 kN/ 3,462 lbf/
Standard/Long 13.6 kN 3,057 lbf
Lift Capacity at Ground Level
2.5 m (98.43 in) 3.0 m (118.11 in) 3.5 m (137.80 in) Maximum
Lift Point Radius Front
kg
Standard Stick 965*
Long Stick and Optional Counterweight 955*
Side Front Side Front Side Front Side
lb kg lb kg lb kg lb kg lb kg lb kg lb kg lb
2,127 560 1,235 730* 1,609 435 959 585* 1,290 355 783 510* 1,124 320 705
2,105 623 1,373 720* 1,587 483 1,065 580* 1,279 394 869 470* 1,036 332 732
* The above loads are in compliance with hydraulic excavator lift capacity rating standard ISO 10567:2007 and they do not exceed
87% of hydraulic lifting capacity or 75% of tipping capacity. The excavator bucket weight is not included on this chart.
