23 120M Motor Grader specifications
Weights
Gross Vehicle Weight – base
– total 14 093 kg 31,069 lb
– front axle 3735 kg 8,233 lb
– rear axle 10 358 kg 22,836 lb
– total with AWD 14,773 kg 32,569 lb
Gross Vehicle Weight – max
– total 20 271 kg 44,690 lb
– front axle 7399 kg 16,312 lb
– rear axle 12 872 kg 28,378 lb
• Base operating weight calculated on standard machine
configuration with 13.00 24 12PR (G-4) tires, full fuel tank,
coolant, lubricants and operator.
Standards
ROPS/FOPS ISO 3471:1992/ISO 3449:1992
Steering ISO 5010:1992
Brakes ISO 3450:1996
Sound ISO 6394:1998/ISO 6395:1988
• The static sound operator pressure level measured
according to ISO 6394:1988 for a cab offered by Caterpillar,
when properly installed, maintained and tested with doors
and windows closed and hydraulic fan at maximum speed
is 70 dB(A).
• The dynamic spectator sound power level for the standard
machine when equipped with sound suppression package
and hydraulic fan running at 70% of maximum speed,
machine sound measured is less than 105 dB(A), complying
with EU 2000/14/EC requirement.
Ripper
Ripping depth, maximum 226.5 mm 8.9 in
Ripper shank holders 5
Ripper shank holder spacing 534 mm 21 in
Penetration force 8024 kg 17,692 lb
Pryout force 2567 kg 5,660 lb
Machine length increase, 1053 mm 41.5 in
beam raised
Scarifier
Front, V-Type, 5 or 11 tooth
Working width 1205 mm 47.4 in
Scarifying depth, maximum 467 mm 18.4 in
Scarifier shank holders 5/11
Scarifier shank holder spacing 116 mm 4.6 in
Mid, V-Type
Working width 1184 mm 46.6 in
Scarifying depth, maximum 292 mm 11.5 in
Scarifier shank holders 11
Scarifier shank holder spacing 116 mm 4.6 in
Mid, straight
Working width 1800 mm 71 in
Scarifying depth, maximum 317 mm 12.5 in
Scarifier shank holders 17
Scarifier shank holder spacing 111 mm 4.4 in
