9
PS-360C specifications
Service Refill Capacities
Liters U.S.
Gallons
Fuel Tank 200 52
Engine Crankcase 7.3 1.9
Hydraulic Tank 90 23.7
Cooling System 28 7.2
Differential 7.5 2
Tire Watering System 394 104
Emulsion Tank 19 5
Ballast Considerations
and Ground Contact
Pressures
The most common method of changing
ground contact pressure is to vary the
tire pressure. Another means to change
ground contact pressure is to alter the
ballast. The ballast compartments are
positioned with a calculated balance of
wheel to weight ratio. Internal-frame
baffles help prevent surges when water
ballasted.
The ballast blocks provide a low center
of gravity, resulting in good stability.
The ballast blocks are positioned in the
bottom of the mainframe near the center
of the machine.
Water System
The pressurized water system is
efficient and reliable. The system
includes stainless steel distribution bars
located over the front and rear tires and
retractable cocoa mats for each tire.
The pressurized system includes triple
water filtration and a powerful Cat
water pump. Cat water pumps are
designed to provide long life.
A polyethylene water tank is located at
the front of the machine on the
operator’s platform. A water level
gauge is on the tank within easy sight of
the operator.
GCP—Ground Contact Pressure CA—Ground Contact Area
Average Ground Contact Pressures
14/70x20, 20-Ply Tires
Tire Pressure kPa
psi
Average Wheel Load
1540 kg (3,390 lb)
GCP
kPa
psi
CA cm 2
in 2
1930 kg (4,250 lb) GCP kPa
psi
CA cm 2
in 2
2505 kg (5,510 lb) GCP kPa
psi
CA cm 2
in 2
2865 kg (6,300 lb) GCP kPa
psi
CA
cm 2
in 2
3575 kg (7,870 lb) GCP kPa
psi
CA cm 2
in 2
20-Ply Tires
241 310 379 448 517 586 655 724 758
35 45 55 65 75 85 95 105 110
Ground Contact Pressures and Contact Areas
296 338 345 372 400 448 469 469 489
43 49 50 54 58 65 68 68 71
509 446 437 405 377 336 322 322 308
79 69 68 63 58 52 50 50 48
317 345 365 386 413 455 469 489 496
46 50 53 56 60 66 68 71 72
596 548 517 490 457 415 403 386 381
92 85 80 76 71 64 63 60 59
338 372 393 413 441 469 510 517 524
49 54 57 60 64 68 74 75 76
725 658 624 592 555 523 480 474 468
112 102 97 92 86 81 74 73 73
351 379 413 434 455 496 524 531 565
51 55 60 63 66 72 76 77 82
797 739 677 645 616 564 535 528 496
124 115 105 100 95 88 83 82 77
372 407 427 462 482 524 558 558 572
54 59 62 67 70 76 81 81 83
940 860 819 758 725 668 627 627 612
146 133 127 117 112 104 97 97 95
