Page 2
61
Dual IGBTMOD™
U-Series Module
300 Amperes/1200 Volts
CM300DU-24H
Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
Outline Drawing and Circuit Diagram
61
Dimensions
Inches
Millimeters
A
4.33
110.0
B
3.15
80.0
C
1.14 +0.04/-0.02 29.0 +1.0/-0.5
D
3.66
±
0.01
93.0
±
0.25
E
2.44
±
0.01
14.0
±
0.25
F
0.83
21.0
G
0.16
4.0
H
0.24
6.0
J
0.59
15.0
K
0.55
14.0
Dimensions
Inches
Millimeters
M
0.33
8.5
P
0.94
24.0
Q
0.98
25.0
R
0.86
21.75
S
M6
M6
T
0.26
6.5
V
0.02
0.5
W
0.110
2.79
X
1.08
27.35
Description:
Powerex IGBTMOD™ Modules
are designed for use in switching
applications. Each module consists
of two IGBT Transistors in a half-
bridge configuration with each
transistor having a reverse-con-
nected super-fast recovery free-
wheel diode. All components and
interconnects are isolated from the
heat sinking baseplate, offering
simplified system assembly and
thermal management.
Features:
□
Low Drive Power
□
Low V
CE(sat)
□
Discrete Super-Fast Recovery
(135ns) Free-Wheel Diode
□
Isolated Baseplate for Easy
Heat Sinking
Applications:
□
AC Motor Control
□
Motion/Servo Control
□
UPS
□
Welding Power Supplies
□
Laser Power Supplies
Ordering Information:
Example: Select the complete
module number you desire from
the table - i.e. CM300DU-24H is a
1200V (V
CES
), 300 Ampere Dual
IGBTMOD™ Power Module.
Current Rating
V
CES
Type
Amperes
Volts (x 50)
CM
300
24
C2E1
E1
G1
E2
C1
G2
E2
T - (4 TYP.)
CM
CL
S - NUTS
(3 TYP)
25
25
C2E1
E2
C1
V - THICK x W - WIDE
TAB (4 PLACES)
E1
E2
G2
G1
A
B
C
D
E
F
G
F
M
K
K
K
Q
Q
J
H
H
R
P
X
