C&H Technology 16FL(R) Series User Manual
Features, Major ratings and characteristics, Fast recovery diodes stud version

Features
Short reverse recovery time
Low stored charge
Wide current range
Excellent surge capabilities
Standard JEDEC types
Stud cathode and stud anode versions
Fully characterised reverse recovery conditions
I
F(AV)
@ T
C
= 100°C
6 *
12 *
6
12
16
A
I
F(RMS)
9.5
19
9.5
19
25
A
I
FSM
@
50Hz
72
145
110
145
180
A
@ 60Hz
75 *
150 *
115
150
190
A
I
2
t
@
50Hz
26
103
60
103
160
A
2
s
@ 60Hz
23
94
55
94
150
A
2
s
I
2
√t
363
856
1452 1452 2290
I
2
√s
V
RRM
range
50 to 400 *
50 to 1000
V
t
rr
range
see table
ns
T
J
range
- 65 to 150
°C
Major Ratings and Characteristics
1N3879- 1N3889-
1N3883 1N3893
Parameters
6FL 12FL 16FL Units
* JEDEC registred values.
FAST RECOVERY DIODES
Stud Version
1N3879(R), 1N3889(R)
6/ 12/ 16FL(R) SERIES
Bulletin PD-2.030 rev
G 01/05
Description
This range of fast recovery diodes is
designed for applications in DC power
supplies, inverters, converters, choppers,
ultrasonic systems and for use as a free
wheeling diode.
case style
DO-203AA (DO-4)
Document Number: 93138
www.vishay.com
1
