Standard Recovery Diodes
(Stud Version), 70 A
70HF(R) Series
Vishay High Power Products
FEATURES
• High surge current capability
• Designed for a wide range of applications
• Stud cathode and stud anode version
• Leaded version available
• Types up to 1600 V V
RRM
• RoHS compliant
• Designed and qualified for industrial level
TYPICAL APPLICATIONS
• Converters
• Power supplies
• Machine tool controls
• Battery charges
ELECTRICAL SPECIFICATIONS
PRODUCT SUMMARY
I
F(AV)
70 A
DO-203AB (DO-5)
RoHS
COMPLIANT
MAJOR RATINGS AND CHARACTERISTICS
PARAMETER TEST CONDITIONS
70HF(R)
UNITS
10 TO 120 140/160
I
F(AV)
70 70 A
T
C
140 110 °C
I
F(RMS)
110 A
I
FSM
50 Hz 1200
A
60 Hz 1250
I 2 t
50 Hz 7100
A 2 s
60 Hz 6450
V
RRM
Range 100 to 1200 1400/1600 V
T
J
- 65 to 180 - 65 to 150 °C
VOLTAGE RATINGS
TYPE
NUMBER VOLTAGE
CODE
V
RRM
, MAXIMUM
REPETITIVE PEAK
REVERSE VOLTAGE
V
V
RSM
, MAXIMUM
NON-REPETITIVE PEAK
REVERSE VOLTAGE
V
V
R(BR)
, MINIMUM
AVALANCHE
VOLTAGE
V
I
RRM
MAXIMUM
AT T
J
= T
J
MAXIMUM
mA
70HF(R)
10 100 200 200
15 20 200 300 300
40 400 500 500
60 600 720 725
9
80 800 960 950
100 1000 1200 1150
120 1200 1440 1350
140 1400 1650 1550
4.5
160 1600 1900 1750
