094 PME-SI
Vishay BCcomponents
Aluminum Capacitors
Power Miniaturized Economy Long Life Snap-In
www.vishay.com
For technical questions, contact:
Document Number: 28382
80
Revision: 04-Dec-09
Table 1
Note
(1)
ESR at 100 Hz is approximately 1.05 x ESR 120 Hz
•
Unless otherwise specified, all electrical values in table 2 apply at
T
amb
= 20
°C, P = 86 kPa to 106 kPa, RH = 45 % to 75 %
ORDERING EXAMPLE
Electrolytic capacitor 094 series
330 µF/400 V; ± 20 %
Nominal case size: Ø 25 mm x 50 mm
2-terminal snap-in:
DIMENSIONS in millimeters, MASS AND PACKAGING QUANTITIES
NOMINAL
CASE SIZE
Ø D x L
Ø D
max.
L
max.
MASS
(g)
PACKAGING QUANTITIES
CARDBOARD BOX DIMENSIONS
L x
W x H
22 x 25
22.5
26.5
≈ 12
216
280 x 240 x 140
22 x 30
22.5
31.5
≈ 16
216
280 x 240 x 140
22 x 35
22.5
36.5
≈ 20
144
280 x 240 x 105
22 x 40
22.5
41.5
≈ 23
144
280 x 240 x 105
22 x 45
22.5
46.5
≈ 26
144
280 x 240 x 140
22 x 50
22.5
51.5
≈ 29
72
280 x 240 x 105
25 x 25
25.5
26.5
≈ 20
216
280 x 240 x 140
25 x 30
25.5
33.5
≈ 22
216
280 x 240 x 140
25 x 35
25.5
36.5
≈ 24
144
280 x 240 x 105
25 x 40
25.5
41.5
≈ 27
144
280 x 240 x 105
25 x 45
25.5
46.5
≈ 32
144
280 x 240 x 140
25 x 50
25.5
51.5
≈ 38
144
280 x 240 x 140
30 x 25
30.5
28.5
≈ 25
168
280 x 240 x 140
30 x 30
30.5
33.5
≈ 30
168
280 x 240 x 140
30 x 35
30.5
38.5
≈ 35
112
280 x 240 x 105
30 x 40
30.5
42.5
≈ 40
112
280 x 240 x 105
30 x 45
30.5
47.5
≈ 45
112
280 x 240 x 140
30 x 50
30.5
52.5
≈ 50
112
280 x 240 x 140
35 x 25
35.5
26.5
≈ 33
126
280 x 240 x 140
35 x 30
35.5
33.5
≈ 40
126
280 x 240 x 140
35 x 35
35.5
36.5
≈ 48
84
280 x 240 x 105
35 x 40
35.5
42.5
≈ 55
84
280 x 240 x 105
35 x 45
35.5
47.5
≈ 63
84
280 x 240 x 140
35 x 50
35.5
52.5
≈ 72
84
280 x 240 x 140
35 x 60
36.5
62.5
≈ 87
42
280 x 240 x 105
ELECTRICAL DATA
SYMBOL
DESCRIPTION
C
R
rated capacitance at 120 Hz
I
R
rated RMS ripple current at 120 Hz, 105
°C
I
L5
max. leakage current after 5 minutes at U
R
ESR
max. equivalent series resistance at 120 Hz
(1)
Ordering code: MAL2 094 46331 E3
Former 12NC: 2222 094 46331
