25ETS..SPbF High Voltage Series
Vishay High Power Products Input Rectifier Diode, 25 A
ELECTRICAL SPECIFICATIONS
PARAMETER SYMBOL TEST CONDITIONS VALUES UNITS
Maximum forward voltage drop V
FM
25 A, T
J
= 25 °C 1.14 V
Forward slope resistance r
t
T
J
= 150 °C
9.62 m
Ω
Threshold voltage V
F(TO)
0.87 V
Maximum reverse leakage current I
RM
T
J
= 25 °C
V
R
= Rated V
RRM
0.1
mA
T
J
= 150 °C 1.0
THERMAL - MECHANICAL SPECIFICATIONS
PARAMETER SYMBOL TEST CONDITIONS VALUES UNITS
Maximum junction and storage
temperature range
T
J
, T
Stg
- 40 to 150 °C
Maximum thermal resistance,
junction to case
R
thJC
DC operation 0.9
°C/W
Maximum thermal resistance,
junction to ambient
R
thJA
62
Typical thermal resistance,
case to heatsink
R
thCS
Mounting surface, smooth and greased 0.5
Approximate weight
2 g
0.07 oz.
Mounting torque
minimum 6 (5) kgf · cm
(lbf · in) maximum 12 (10)
Marking device Case style D 2 PAK (SMD-220)
25ETS08S
25ETS12S
