Document Number: 94255
For technical questions, contact: [email protected]
www.vishay.com
Revision: 13-Aug-08
1
Schottky Rectifier
New Generation 3 D-61 Package, 2 x 40 A
80CNQ...APbF
Vishay High Power Products
FEATURES
• 150 °C T
J
operation
• Center tap module
• Very low forward voltage drop
• High frequency operation
• High purity, high temperature epoxy encapsulation for
enhanced mechanical strength and moisture resistance
• Guard ring for enhanced ruggedness and long term
reliability
• New fully transfer-mould low profile, small footprint, high
current package
• Through-hole versions are currently available for use in
lead (Pb)-free applications (“PbF” suffix)
• Designed and qualified for industrial level
DESCRIPTION
The center tap Schottky rectifier module series has been
optimized for very low forward voltage drop, with moderate
leakage. The proprietary barrier technology allows for
reliable operation up to 150 °C junction temperature. Typical
applications are in switching power supplies, converters,
freewheeling diodes, and reverse battery protection.
PRODUCT SUMMARY
I
F(AV)
2 x 40 A
V
R
35 to 45 V
Base
common
cathode
Common
cathode
Anode
2
Anode
1
1
2
3
D-61-8
Available
RoHS*
COMPLIANT
MAJOR RATINGS AND CHARACTERISTICS
SYMBOL
CHARACTERISTICS
VALUES
UNITS
I
F(AV)
Rectangular waveform
80
A
V
RRM
Range
35 to 45
V
I
FSM
t
p
= 5 µs sine
5800
A
V
F
40 Apk, T
J
= 125 °C (per leg)
0.47
V
T
J
Range
- 55 to 150
°C
VOLTAGE RATINGS
PARAMETER
SYMBOL 80CNQ035APbF 80CNQ040APbF
80CNQ045APbF
UNITS
Maximum DC reverse voltage
V
R
35
40
45
V
Maximum working peak reverse voltage
V
RWM
ABSOLUTE MAXIMUM RATINGS
PARAMETER SYMBOL
TEST
CONDITIONS
VALUES
UNITS
Maximum average forward current
See fig. 5
per leg
I
F(AV)
50 % duty cycle at T
C
= 114 °C, rectangular waveform
40
A
per device
80
Maximum peak one cycle
non-repetitive surge current per leg
See fig. 7
I
FSM
5 µs sine or 3 µs rect. pulse
Following any rated
load condition and with
rated V
RRM
applied
5800
10 ms sine or 6 ms rect. pulse
750
Non-repetitive avalanche energy per leg
E
AS
T
J
= 25 °C, I
AS
= 8 A, L = 1.7 mH
54
mJ
Repetitive avalanche current per leg
I
AR
Current decaying linearly to zero in 1 µs
Frequency limited by T
J
maximum V
A
= 1.5 x V
R
typical
8
A
* Pb containing terminations are not RoHS compliant, exemptions may apply
