123NQ100PbF
Vishay High Power Products Schottky Rectifier, 120 A
Fig. 5 - Maximum Allowable Case Temperature vs.
Average Forward Current
Fig. 6 - Forward Power Loss Characteristics
Fig. 7 - Maximum Non-Repetitive Surge Current
Fig. 8 - Unclamped Inductive Test Circuit
Note
(1) Formula used: T
C
= T
J
- (Pd + Pd
REV
) x R
thJC
;
Pd = Forward power loss = I
F(AV)
x V
FM
at (I
F(AV)
/D) (see fig. 6);
Pd
REV
= Inverse power loss = V
R1
x I
R
(1 - D); I
R
at V
R1
= Rated V
R
I
F(AV)
- Average Forward Current (A)
Allowable Case Temperature (°C)
100
120
140
180
0 60 120 180 30 90 150
160
110
DC
Square wave (D = 0.50)
80 % rated V
R
applied
See note (1)
170
150
130
I
F(AV)
- Average Forward Current (A)
Average Power Loss (W)
0 20 40 60 80 100 120 180
0
20
60
120
140
80
40
100
160
D = 0.20
D = 0.25
D = 0.33
D = 0.50
D = 0.75
DC
RMS limit
t
p
- Square Wave Pulse Duration (µs)
I FSM
- Non-Repetitive Surge Current (A)
10 100 1000 10 000
100
100 000
1000
10 000
Current
monitor
High-speed
switch
D.U.T.
R
g
= 25 Ω
+
Freewheel
diode
V
d
= 25 V
L
IRFP460
40HFL40S02
