Document Number: 94352 For technical questions, contact: [email protected] www.vishay.com
Revision: 29-Apr-08 1
Three Phase Bridge
(Power Modules), 90/110 A
90-110MT.KPbF Series
Vishay High Power Products
FEATURES
• Package fully compatible with the industry
standard INT-A-PAK power modules series
• High thermal conductivity package, electrically
insulated case
• Excellent power volume ratio, outline for easy connections
to power transistor and IGBT modules
• 4000 V
RMS
isolating voltage
• UL E78996 approved
• Totally lead (Pb)-free
• Designed and qualified for industrial level
DESCRIPTION
A range of extremely compact, encapsulated three phase
bridge rectifiers offering efficient and reliable operation. They
are intended for use in general purpose and heavy duty
applications.
ELECTRICAL SPECIFICATIONS
PRODUCT SUMMARY
I
O
90/110 A
MTK
RoHS
COMPLIANT
MAJOR RATINGS AND CHARACTERISTICS
SYMBOL CHARACTERISTICS 90MT.K 110MT.K UNITS
I
O
90 (120) 110 (150) A
T
C
90 (61) 90 (57) °C
I
FSM
50 Hz 770 950
A
60 Hz 810 1000
I 2 t
50 Hz 3000 4500
A 2 s
60 Hz 2700 4100
I 2 √t
30 000 45 000 A 2 √s
V
RRM
Range 800 to 1600 V
T
Stg
Range - 40 to 150 °C
T
J
VOLTAGE RATINGS
TYPE NUMBER
VOLTAGE
CODE
V
RRM
, MAXIMUM
REPETITIVE PEAK
REVERSE VOLTAGE
V
V
RSM
, MAXIMUM
NON-REPETITIVE PEAK
REVERSE VOLTAGE
V
I
RRM
MAXIMUM
AT T
J
= MAXIMUM
mA
90-110MT..K
80 800 900
10
100 1000 1100
120 1200 1300
140 1400 1500
160 1600 1700
