Document Number: 28363 For technical questions, contact: [email protected] www.vishay.com
Revision: 07-Dec-09 109
199 PEL-SI
Aluminum Capacitors
Power Economy Long Life Snap-In
Vishay BCcomponents
160
1000 35 x 30 1.82 1.50 0.25 157 31102E3
1200 25 x 50 2.24 1.50 0.14 105 51122E3
1200 30 x 40 2.06 1.50 0.21 124 41122E3
1200 35 x 30 1.81 1.50 0.21 152 31122E3
1500 30 x 45 2.30 1.50 0.11 106 51152E3
1500 35 x 35 1.97 1.50 0.17 134 41152E3
1800 30 x 50 2.51 1.50 0.09 92 51182E3
1800 35 x 45 2.45 1.50 0.14 102 41182E3
2200 35 x 50 2.66 1.50 0.11 90 51222E3
200
330 22 x 35 1.19 1.32 0.50 241 42331E3
390 22 x 35 1.27 1.50 0.43 212 42391E3
390 25 x 30 1.27 1.50 0.43 219 52391E3
470 30 x 25 1.28 1.50 0.35 231 52471E3
560 30 x 30 1.53 1.50 0.30 180 52561E3
680 30 x 30 1.57 1.50 0.24 167 52681E3
680 35 x 25 1.36 1.50 0.37 225 62681E3
820 25 x 50 2.04 1.50 0.20 115 32821E3
820 30 x 35 1.75 1.50 0.20 146 42821E3
820 35 x 30 1.72 1.50 0.30 160 52821E3
1000 30 x 45 2.14 1.50 0.17 113 42102E3
1000 35 x 35 1.90 1.50 0.25 140 52102E3
1200 30 x 50 2.36 1.50 0.14 98 42122E3
1500 35 x 45 2.31 1.50 0.17 104 52152E3
1800 35 x 50 2.52 1.50 0.14 92 52182E3
250
220 22 x 30 1.14 1.10 0.75 294 43221E3
220 25 x 25 0.94 1.10 0.75 317 53221E3
270 22 x 35 1.11 1.35 0.61 240 43271E3
270 25 x 30 1.12 1.35 0.61 247 53271E3
270 30 x 25 1.11 1.35 0.61 274 63271E3
330 22 x 40 1.27 1.50 0.50 199 33331E3
330 25 x 30 1.20 1.50 0.50 216 43331E3
330 30 x 25 1.17 1.50 0.50 250 53331E3
390 25 x 35 1.35 1.50 0.43 186 43391E3
390 30 x 30 1.38 1.50 0.43 196 53391E3
470 25 x 40 1.52 1.50 0.35 158 33471E3
470 30 x 30 1.43 1.50 0.35 181 43471E3
470 35 x 25 1.28 1.50 0.53 240 53471E3
560 30 x 35 1.60 1.50 0.30 158 53561E3
560 35 x 30 1.59 1.50 0.44 172 63561E3
680 30 x 40 1.79 1.50 0.24 135 43681E3
680 35 x 35 1.76 1.50 0.37 150 53682E3
820 30 x 45 2.00 1.50 0.20 116 43821E3
820 35 x 35 1.77 1.50 0.30 147 53821E3
820 35 x 40 1.96 1.50 0.30 130 63821E3
1000 35 x 40 1.96 1.50 0.25 127 53102E3
1000 35 x 45 2.17 1.50 0.25 111 63102E3
1200 35 x 45 2.16 1.50 0.21 110 43122E3
1200 35 x 50 2.38 1.50 0.21 98 53122E3
ELECTRICAL DATA AND ORDERING INFORMATION
U
R
(V)
C
R
120 Hz
(µF)
NOMINAL
CASE SIZE
Ø D x L
(mm)
I
R
120 Hz
(A)
I
L5
(mA)
MAX. ESR
120 Hz (1)
( Ω)
MAX. Z
10 kHz
(m Ω)
ORDERING
CODE
MAL2199.......
