Major Ratings and Characteristics
I
F(AV)
Sinusoidal
waveform
V
RRM
800 to 1200 V
I
FSM
300 A
V
F
@ 10 A, T
J
= 25°C 1.0 V
T
J
- 40 to 150 °C
Characteristics Values Units
20 A
Output Current in Typical Applications
Single-phase Bridge Three-phase Bridge Units
Description/ Features
The 20ETS...SPbF rectifier SAFE IR series has
been optimized for very low forward voltage drop,
with moderate leakage. The glass passivation
technology used has reliable operation up to 150°C
junction temperature.
Typical applications are in input rectification and
these products are designed to be used with
International Rectifier Switches and Output
Rectifiers which are available in identical package
outlines.
Capacitive input filter T A = 55°C, T J = 125°C,
16.3 21 A
common heatsink of 1°C/W
INPUT RECTIFIER DIODE
Lead-Free ("PbF" suffix)
V
F
< 1V @ 10A
I
FSM
= 300A
V
RRM
= 800 - 1200V
SAFE
IR Series
20ETS...SPbF
Bulletin I2209 rev A 08/06
D
2
Pak (SMD-220)
Package Outline
Document Number: 94340 www.vishay.com
