303CNQ100PbF
Vishay High Power Products Schottky Rectifier, 300 A
Fig. 5 - Maximum Allowable Case Temperature vs.
Average Forward Current (Per Leg)
Fig. 6 - Forward Power Loss Characteristics (Per Leg)
Fig. 7 - Maximum Non-Repetitive Surge Current (Per Leg)
Fig. 8 - Unclamped Inductive Test Circuit
Note
(1) Formula used: T
C
= T
J
- (Pd + Pd
REV
) x R
thJC
;
Pd = Forward power loss = I
F(AV)
x V
FM
at (I
F(AV)
/D) (see fig. 6);
Pd
REV
= Inverse power loss = V
R1
x I
R
(1 - D); I
R
at V
R1
= 80 % rated V
R
100
140
170
160
150
130
120
110
180
Allowable Case Temperature (°C)
I
F(AV)
- Average Forward Current (A)
50 150 200 100 0 250
DC
Square wave (D = 0.50)
80 % rated V
R
applied
See note (1)
0
125
25
50
75
100
150
Average Power Loss (W)
I
F(AV)
- Average Forward Current (A)
40 120 240 160 80 0 200
DC
RMS limit
D = 0.08
D = 0.17
D = 0.25
D = 0.33
D = 0.50
1000
10 000
100 000
I FSM
- Non-Repetitive Surge Current (A)
t
p
- Square Wave Pulse Duration (µs)
100 10 000 1000 10
At any rated load condition
and with rated V
RRM
applied
following surge
Current
monitor
High-speed
switch
D.U.T.
R
g
= 25 Ω
+
Freewheel
diode
V
d
= 25 V
L
IRFP460
40HFL40S02
