C&H Technology C089D Bar Clamps User Manual
C089d bar clamps
SPECIALISTS IN POWER ELECTRONIC COMPONENTS AND ASSEMBLIES
www.chtechnology.com
6121 Baker Road,
Suite 108
Minnetonka, MN 55345
Phone (952) 933-6190
Fax (952) 933-6223
1-800-274-4284
Note: Bolt insulator dimension “H” available in either 24mm or 14mm height.
C089D Bar Clamps
WITH PRECALIBRATED FORCE
BOLT INTERAXYS – 89 MM
PRESET PRESSURE UP TO 21 KN
MAXIMUM PUK DIAMETER – 76MM
ORDERING INFORMATION EXAMPLE: C089D-18KN-110
CLAMP MODEL BOLT LENGTH= 110MM
PRECALIBRATED CLAMPING FORCE = 18KN Note: Additional bolt lengths available
