INPUT RECTIFIER DIODE
TO-220 FULLPAK
Bulletin I2134 rev. C 03/99
V
F
< 1V @ 10A
I
FSM
= 300A
V
RRM
800 to 1600V
SAFE IR Series
20ETS..FP
Major Ratings and Characteristics
I
F(AV)
Sinusoidal
waveform
V
RRM
800 to 1600 V
I
FSM
300 A
V
F
@ 10 A, T
J
= 25°C 1.0 V
T
J
- 40 to 150 °C
Characteristics 20ETS..FP Units
20 A
TO-220 FULLPAK Output Current in Typical Applications
Applications Single-phase Bridge Three-phase Bridge Units
Description/Features
The 20ETS..FP rectifier SAFE IR series has been
optimized for very low forward voltage drop, with
moderate leakage. The glass passivation
technology used has reliable operation up to 150°C
junction temperature.
Typical applications are in input rectification and
these products are designed to be used with
International Rectifier Switches and Output
Rectifiers which are available in identical package
outlines. Fully isolated package (V
INS
= 2500 V
RMS
). UL E78996 approved
Capacitive input filter T A = 55°C, T J = 125°C,
18 22 A
common heatsink of 1°C/W
Package Outline
