Page 2
71
Four IGBTMOD™
U-Series Module
100 Amperes/600 Volts
CM100BU-12H
Powerex, Inc., 200 E. Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
Outline Drawing and Circuit Diagram
71
Dimensions
Inches
Millimeters
A
2.83
72.0
B
3.58
91.0
C
1.16
+0.04/-0.02 29.5 +1.0/-0.5
D
2.17±0.01
55.0±0.25
E
2.91±0.01
74.0±0.25
F
0.16
4.0
G
1.02
26.0
H
0.31
8.1
J
0.79
20.0
K
0.39
10.0
L
0.43
11.0
Dimensions
Inches
Millimeters
M
0.74
18.7
N
0.75
19.1
P
0.57
14.4
Q
1.55
39.3
R
0.
05 1.25
S
M4
M4
T
0.22 Dia.
5.5 Dia.
U
1.61
41.0
V
0.69
17.5
W
0.02
0.5
X
0.110
2.79
Description:
Powerex IGBTMOD™ Modules
are designed for use in switching
applications. Each module consists
of four IGBT Transistors in an
H-Bridge configuration, with each
transistor having a reverse-con-
nected super-fast recovery free-
wheel diode. All components and
interconnects are isolated from the
heat sinking baseplate, offering
simplified system assembly and
thermal management.
Features:
£
Low Drive Power
£
Low V
CE(sat)
£
Discrete Super-Fast Recovery
(70ns) Free-Wheel Diode
£
Isolated Baseplate for Easy
Heat Sinking
Applications:
£
AC Motor Control
£
Motion/Servo Control
£
UPS
£
Welding Power Supplies
£
Laser Power Supplies
Ordering Information:
Example: Select the complete
module number you desire from
the table - i.e. CM100BU-12H is a
600V (V
CES
), 100 Ampere Four-
IGBT IGBTMOD™ Power Module.
Current Rating
V
CES
Type
Amperes
Volts (x 50)
CM
100
12
G
V
P
U
G
U
P E
U
P
S - NUTS
(4 TYP)
V
G
U
N E
U
N
E
V
P
T - (4 TYP.)
E
U
N
N
G
U
N
U
E
U
P
E
V
N
G
V
N
V
E
V
P
G
U
P
P
G
V
P
G
V
N E
V
N
TYP
TYP
W - THICK x X - WIDE
TAB (8 PLACES)
D
J
A
C
H
G
F
TYP
K
N
E
B
L
K
Q
R
M
L
R
U
P
V
L
N
L
P
N
P
