INPUT RECTIFIER DIODE
Bulletin I2120 rev. A 07/97
SAFE IR Series
10ETS..
V
F
< 1.1V @ 10A
I
FSM
= 200A
V
RRM
800 to 1600V
Major Ratings and Characteristics
Characteristics 10ETS.. Units
I
F(AV)
Sinusoidal waveform 10 A
V
RRM
800 to 1600 V
I
FSM
200 A
V
F
@ 10 A, T
J
= 25°C 1.1 V
T
J
- 40 to 150 °C
TO-220AC
Description/Features
The 10ETS.. rectifier SAFE IR series has been
optimized for very low forward voltage drop,
with moderate leakage. The glass passivation
technology used has reliable operation up to
150°C junction temperature.
The
High Reverse Voltage range available
allows design of input stage primary
rectification with
Outstanding Voltage Surge
capability.
Typical applications are in input rectification
and these products are designed to be used
with International Rectifier Switches and
Output Rectifiers which are available in
identical package outlines.
Also available in D-pak (8EWS Series)
Capacitive input filter T
A
= 55°C, T
J
= 125°C
12.0 16.0 A
common heatsink of 1°C/ W
Output Current in Typical Applications
Applications Single-phase Bridge Three-phase Bridge Units
Package Outline
Document Number: 93484 www.vishay.com
1
