Outline Dimensions
D-61-8, D-61-8-SM,
D-61-8-SL
Vishay High Power Products
DIMENSIONS FOR D 61-8-SL in millimeters (inches)
8.89 (0.350)
8.73 (0.344)
2.67 (0.105)
2.16 (0.085)
19.93 (0.785)
19.68 (0.775)
5.59 (0.220)
5.08 (0.200)
0.89 (0.035)
0.73 (0.029)
1.98 (0.078)
1.72 (0.068)
5.20 (0.205)
4.95 (0.195)
14° MIN. 14° MIN.
3.30 (0.130)
3.05 (0.120)
1.40 (0.055)
1.14 (0.045)
R0 0.508
(R 0.02)
5.97 (0.235)
5.71 (0.225)
DETAIL “A”
3.30 (0.130)
3.05 (0.120)
5°
1.04 (0.041)
0.84 (0.033)
R 0.51 (0.020)
R 0.76 (0.030)
5.33 (0.210)
3.97 (0.156)
3.68 (0.145)
2.41 (0.095)
2.16 (0.085)
0.89 (0.035)
0.73 (0.029)
10.79 (0.425) MAX.
19.93 (0.785)
19.68 (0.775)
16.13 (0.635)
15.88 (0.625)
14.22 (0.560)
13.71 (0.540)
1.98 (0.078)
1.72 (0.068)
(2 x)
10.16 (0.400) REF.
0.89 (0.035)
0.73 (0.029)
(2 x)
0.64 (0.025) REF.
(2 x)
8.89 (0.350)
8.73 (0.344)
3.97 (0.156)
3.68 (0.145)
5.59 (0.220)
5.08 (0.200)
