139
Chopper IGBTMOD™
U-Series Module
150 Amperes/1200 Volts
CM150E3U-24H
Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
Outline Drawing and Circuit Diagram
Description:
Powerex Chopper IGBTMOD™
Modules are designed for use in
switching applications. Each module
consists of one IGBT Transistor
having a reverse-connected super-
fast recovery free-wheel diode and
an anode-collector connected super-
fast recovery free-wheel diode. All
components and interconnects are
isolated from the heat sinking base-
plate, offering simplified system
assembly and thermal management
.
Features:
□
Low Drive Power
□
Low V
CE(sat)
□
Discrete Super-Fast Recovery
Free-Wheel Diode
□
High Frequency Operation
(15-20kHz)
□
Isolated Baseplate for Easy
Heat Sinking
Applications:
□
DC Motor Control
□
Boost Regulator
Ordering Information:
Example: Select the complete
module number you desire from the
table - i.e. CM150E3U-24H is a
1200V (V
CES
), 150 Ampere Chopper
IGBTMOD™ Power Module.
Current Rating
V
CES
Type
Amperes
Volts (x 50)
CM
150
24
139
Dimensions
Inches
Millimeters
A
4.25
108.0
B
2.44
62.0
C
1.14 +0.04/-0.02 29.0 +1.0/-0.5
D
3.66
±
0.01
93.0
±
0.25
E
1.88
±
0.01
48.0
±
0.25
F
0.30
7.5
G
0.16
4.0
H
0.24
6.0
J
0.11
2.8
K
0.71
18.0
Dimensions
Inches
Millimeters
L
0.87
22.0
M
0.33
8.5
N
0.10
2.5
P
0.85
21.5
Q
0.98
25.0
R
0.16
4.0
S
M6
M6
T
0.26 Dia. 6.5 Dia.
U
0.02
0.5
C2E1
E2
C1
E2
G2
S - NUTS (3 TYP)
CM
T - (4 TYP.)
C2E1
E2
CL
C1
E2
G2
K
D
C
A
E
B
K
K
L
R
M
P
Q
Q
U
N
F
G
H
F
