CM400DU-24NFH
Dual IGBTMOD™ NFH-Series Module
400 Amperes/1200 Volts
Powerex, Inc., 173 Pavilion Lane, Youngwood, Pennsylvania 15697 (724) 925-7272 www.pwrx.com
2 7/11 Rev. 2
Absolute Maximum Ratings, Tj = 25 °C unless otherwise specified
Ratings Symbol CM400DU-24NFH Units
Junction Temperature Tj –40 to 150 °C
Storage Temperature Tstg –40 to 125 °C
Collector-Emitter Voltage (G-E Short) VCES 1200 Volts
Gate-Emitter Voltage (C-E Short) VGES ±20 Volts
Collector Current (TC = 25°C) IC 400* Amperes
Peak Collector Current ICM 800* Amperes
Emitter Current** (TC = 25°C) IE 400* Amperes
Peak Emitter Current** IEM 800* Amperes
Maximum Collector Dissipation (TC = 25°C, Tj ≤ 150°C) PC 1040 Watts
Maximum Collector Dissipation (TC' = 25°C, Tj' ≤ 150°C) PC 2500 Watts
Mounting Torque, M6 Main Terminal — 40 in-lb
Mounting Torque, M6 Mounting — 40 in-lb
Weight — 580 Grams
Isolation Voltage (Main Terminal to Baseplate, AC 1 min.) VISO 2500 Volts
Static Electrical Characteristics, Tj = 25 °C unless otherwise specified
Characteristics Symbol Test Conditions Min. Typ. Max. Units
Collector-Cutoff Current ICES VCE = VCES, VGE = 0V — — 1.0 mA
Gate Leakage Current IGES VGE = VGES, VCE = 0V — — 1.4 µA
Gate-Emitter Threshold Voltage VGE(th) IC = 40mA, VCE = 10V 4.5 6.0 7.5 Volts
Collector-Emitter Saturation Voltage VCE(sat) IC = 400A, VGE = 15V, Tj = 25°C — 5.0 6.5 Volts
IC = 400A, VGE = 15V, Tj = 125°C — 5.0 — Volts
Total Gate Charge QG VCC = 600V, IC = 400A, VGE = 15V — 1800 — nC
Emitter-Collector Voltage** VEC IE = 400A, VGE = 0V — — 3.5 Volts
Dynamic Electrical Characteristics, Tj = 25 °C unless otherwise specified
Characteristics Symbol Test Conditions Min. Typ. Max. Units
Input Capacitance Cies — — 63 nF
Output Capacitance Coes VCE = 10V, VGE = 0V — — 5.3 nF
Reverse Transfer Capacitance Cres — — 1.2 nF
Inductive Turn-on Delay Time td(on) — — 300 ns
Load Rise Time tr VCC = 600V, IC = 400A, — — 100 ns
Switch Turn-off Delay Time td(off) VGE1 = VGE2 = 15V, RG = 0.78Ω, — — 500 ns
Time Fall Time tf Inductive Load — — 150 ns
Diode Reverse Recovery Time** trr Switching Operation, — — 250 ns
Diode Reverse Recovery Charge** Qrr IE = 400A — 16 — µC
* Pulse width and repetition rate should be such that device junction temperature (Tj) does not exceed Tj(max) rating.
**Represents characteristics of the anti-parallel, emitter-to-collector free-wheel diode (FWDi).
