Major Ratings and Characteristics
Characteristics
10ETS..
Units
I
F(AV)
Sinusoidal waveform
10
A
V
RRM
Range
800 to 1200
V
I
FSM
200
A
V
F
@
10 A, T
J
= 25°C
1.1
V
T
J
- 40 to 150
°C
Capacitive input filter T
A
= 55°C, T
J
= 125°C
12.0
16.0
A
common heatsink of 1°C/ W
Output Current in Typical Applications
Applications
Single-phase Bridge
Three-phase Bridge
Units
INPUT RECTIFIER DIODE
SAFE
IR
Series
10ETS12, 10ETS12S
Bulletin I2121 rev. C 12/01
TO-220AC
Package Outline
D
2
Pak (SMD-220)
Package Outline
Description/Features
The 10ETS.. rectifier SAFE
IR
series has been
optimized for very low forward voltage drop, with
moderate leakage. The glass passivation
technology used has reliable operation up to 150°C
junction temperature.
Typical applications are in input rectification and
these products are designed to be used with
International Rectifier Switches and Output
Rectifiers which are available in identical package
outlines.
V
F
< 1V @ 10A
I
FSM
= 200A
V
RRM
800 to 1200V
Document Number: 93486
