093 PMG-SI
Vishay BCcomponents
Aluminum Capacitors
Power Miniaturized General Purpose Snap-In
www.vishay.com
For technical questions, contact:
Document Number: 28383
38
Revision: 04-Dec-09
Notes
(1)
ESR at 100 Hz is approximately 1.05 x ESR 120 Hz
• Unless otherwise specified, all electrical values in table 2 apply at
T
amb
=
20 °C, P = 86 kPa to 106 kPa, RH = 45 % to 75 %
ORDERING EXAMPLE
Electrolytic capacitor 093 series
330 µF/400 V; ± 20 %
Nominal case size: Ø 25 mm x 40 mm
2-terminal snap-in:
Table 2
ELECTRICAL DATA
SYMBOL
DESCRIPTION
C
R
rated capacitance at 120 Hz
I
R
rated RMS ripple current at 120 Hz, 85
°C
I
L5
max. leakage current after 5 minutes at U
R
ESR
max. equivalent series resistance at 120 Hz
(1)
Ordering code: MAL2 093 46331 E3
Former 12NC: 2222 093 46331
ELECTRICAL DATA AND ORDERING INFORMATION
U
R
(V)
C
R
120 Hz
(µF)
NOMINAL
CASE SIZE
Ø D x L
(mm)
I
R
120 Hz
(A)
I
L5
(mA)
MAX. ESR
(1)
120 Hz
(
Ω)
MAX. Z
10 kHz
(
Ω)
ORDERING CODE
MAL2093.......
270
22 x 25
1.26
1.08
0.47
0.31
52271E3
390
22 x 30
1.55
1.50
0.33
0.22
52391E3
390
25 x 25
1.46
1.50
0.36
0.25
42391E3
470
22 x 35
1.78
1.50
0.27
0.18
52471E3
560
25 x 30
1.83
1.50
0.25
0.17
42561E3
200
680
25 x 35
2.06
1.50
0.21
0.15
42681E3
820
25 x 40
2.36
1.50
0.18
0.12
42821E3
1000
30 x 35
2.35
1.50
0.18
0.13
32102E3
1200
30 x 40
2.69
1.50
0.15
0.11
32122E3
1500
30 x 45
3.00
1.50
0.12
0.09
32152E3
1800
30 x 50
3.36
1.50
0.11
0.08
32182E3
1800
35 x 40
2.91
1.50
0.14
0.10
22182E3
2200
35 x 45
3.23
1.50
0.12
0.09
22222E3
220
22 x 25
1.18
1.10
0.50
0.32
53221E3
270
22 x 30
1.37
1.35
0.40
0.25
53271E3
330
22 x 35
1.58
1.50
0.32
0.20
53331E3
390
22 x 35
1.67
1.50
0.29
0.18
53391E3
390
25 x 30
1.64
1.50
0.29
0.19
43391E3
470
25 x 35
1.85
1.50
0.25
0.16
43471E3
250
560
25 x 40
2.11
1.50
0.21
0.14
43561E3
680
30 x 30
2.01
1.50
0.22
0.15
33681E3
820
30 x 35
2.23
1.50
0.19
0.13
33821E3
1000
30 x 40
2.56
1.50
0.15
0.11
33102E3
1200
35 x 40
3.82
1.50
0.15
0.11
23122E3
1500
35 x 45
3.08
1.50
0.13
0.09
23152E3
1800
35 x 50
3.35
1.50
0.11
0.08
23182E3
400
68
22 x 25
0.80
0.54
2.06
1.49
56689E3
100
22 x 25
0.98
0.80
1.48
1.09
56101E3
150
22 x 30
1.11
1.20
1.00
0.74
56151E3
150
25 x 25
1.10
1.20
1.03
0.77
46151E3
180
22 x 35
1.26
1.44
0.83
0.61
56181E3
180
25 x 30
1.27
1.44
0.81
0.59
46181E3
220
22 x 40
1.46
1.50
0.68
0.50
56221E3
220
25 x 30
1.38
1.50
0.70
0.52
46221E3
220
30 x 25
1.43
1.50
0.71
0.53
36221E3
270
22 x 50
1.58
1.50
0.53
0.39
56271E3
270
30 x 25
1.53
1.50
0.63
0.48
36271E3
330
25 x 40
1.82
1.50
0.49
0.37
46331E3
330
30 x 30
1.77
1.50
0.50
0.39
36331E3
330
35 x 25
1.77
1.50
0.58
0.46
26331E3
390
25 x 50
2.21
1.50
0.40
0.30
46391E3
390
30 x 35
1.98
1.50
0.43
0.33
36391E3
390
35 x 30
2.10
1.50
0.44
0.34
26391E3
470
30 x 40
2.20
1.50
0.37
0.28
36471E3
470
35 x 30
2.14
1.50
0.40
0.32
26471E3
560
30 x 45
2.48
1.50
0.30
0.23
36561E3
560
35 x 35
2.35
1.50
0.34
0.27
26561E3
680
35 x 40
2.68
1.50
0.28
0.22
26681E3
820
35 x 50
3.18
1.50
0.22
0.17
26821E3
