Document Number: 93411
For technical questions, contact: [email protected]
www.vishay.com
Revision: 02-Sep-08
1
Schottky Rectifier
New Generation 3 D-61 Package, 2 x 40 A
88CNQ060A Series
Vishay High Power Products
FEATURES
• 150 °C T
J
operation
• Center tap module
• Low forward voltage drop
• High frequency operation
• Guard ring for enhanced ruggedness and long term
reliability
• High purity, high temperature epoxy encapsulation for
enhanced mechanical strength and moisture resistance
• New fully transfer-mold low profile, small footprint, high
current package
• Designed and qualified for industrial level
DESCRIPTION
The center tap Schottky rectifier module has been optimized
for very low forward voltage drop with moderate leakage.
The proprietary barrier technology allows for reliable
operation up to 150 °C junction temperature. Typical
applications are in switching power supplies, converters,
freewheeling diodes, and reverse battery protection.
PRODUCT SUMMARY
I
F(AV)
2 x 40 A
V
R
60 V
I
RM
240 mA at 125 °C
Base
common
cathode
Base
common
cathode
Common
cathode
Anode
2
Anode
1
1
2
3
Common
cathode
Anode
2
Anode
1
1
2
3
Anode
2
Anode
1
1
3
D-61-8
88CNQ060A
88CNQ060ASM
D-61-8-SM
88CNQ060ASL
D-61-8-SL
MAJOR RATINGS AND CHARACTERISTICS
SYMBOL
CHARACTERISTICS
VALUES
UNITS
I
F(AV)
Rectangular waveform
80
A
V
RRM
60
V
I
FSM
t
p
= 5 µs sine
5000
A
V
F
40 Apk, T
J
= 125 °C (per leg)
0.56
V
T
J
Range
- 55 to 150
°C
VOLTAGE RATINGS
PARAMETER
SYMBOL
88CNQ060A
UNITS
Maximum DC reverse voltage
V
R
60
V
Maximum working peak reverse voltage
V
RWM
