158 PUL-SI
Aluminum Capacitors
Power Ultra Long Life Snap-In
Vishay BCcomponents
40
2200 22 x 25 2.17 2.65 0.18 131 100 17222E3 57222E3
3300 22 x 30 2.73 3.33 0.27 91 70 17332E3 57332E3
3900 22 x 35 3.12 3.81 0.32 77 59 17392E3 57392E3
3900 25 x 30 3.02 3.68 0.32 83 65 27392E3 67392E3
4700 22 x 40 3.52 4.29 0.38 65 51 17472E3 57472E3
5600 25 x 35 3.53 4.31 0.45 63 51 27562E3 67562E3
6800 30 x 30 3.39 4.14 0.55 69 56 37682E3 77682E3
8200 25 x 50 4.72 5.76 0.66 44 36 27822E3 67822E3
8200 30 x 35 3.90 4.76 0.66 57 47 37822E3 77822E3
10 000 30 x 40 4.36 5.32 0.80 48 40 37103E3 77103E3
12 000 35 x 35 4.00 4.88 0.96 56 45 47123E3 87123E3
15 000 35 x 45 4.99 6.09 1.20 42 35 47153E3 87153E3
18 000 35 x 50 5.36 6.54 1.44 38 31 47183E3 87183E3
50
1500 22 x 25 1.99 2.43 0.15 148 102 11152E3 51152E3
2200 22 x 30 2.50 3.05 0.22 104 73 11222E3 51222E3
2700 22 x 35 2.88 3.51 0.27 85 60 11272E3 51272E3
2700 25 x 30 2.81 3.43 0.27 91 66 21272E3 61272E3
3300 22 x 40 3.27 3.99 0.33 71 51 11332E3 51332E3
3300 25 x 35 3.23 3.94 0.33 75 55 21332E3 61332E3
3900 25 x 40 3.62 4.42 0.39 64 47 21392E3 61392E3
4700 30 x 30 3.24 3.95 0.47 74 57 31472E3 71472E3
5600 25 x 50 4.43 5.40 0.56 48 36 21562E3 61562E3
5600 30 x 35 3.73 4.55 0.56 61 47 31562E3 71562E3
6800 30 x 40 4.17 5.09 0.68 52 41 31682E3 71682E3
8200 35 x 35 3.88 4.73 0.82 61 46 41822E3 81822E3
10 000 35 x 40 4.33 5.28 1.00 52 40 41103E3 81103E3
12 000 35 x 45 4.72 5.76 1.20 46 35 41123E3 81123E3
63
1200 22 x 25 2.07 2.53 0.16 137 100 18122E3 58122E3
1500 22 x 30 2.49 3.04 0.19 107 78 18152E3 58152E3
2200 22 x 35 3.00 3.66 0.26 79 58 18222E3 58222E3
2200 25 x 30 2.90 3.54 0.28 85 64 28222E3 68222E3
2700 25 x 35 3.34 4.07 0.34 70 53 28272E3 68272E3
3300 25 x 40 3.76 4.59 0.42 59 45 28332E3 68332E3
3300 30 x 30 3.28 4.00 0.42 74 58 38332E3 78332E3
3900 30 x 35 3.77 4.60 0.50 61 48 38392E3 78392E3
4700 30 x 40 4.22 5.15 0.60 52 41 38472E3 78472E3
5600 35 x 35 3.97 4.84 0.71 59 47 48562E3 88562E3
6800 30 x 50 5.04 6.15 0.86 40 33 38682E3 78682E3
6800 35 x 40 4.42 5.39 0.86 51 40 48682E3 88682E3
8200 35 x 45 4.82 5.88 1.04 45 35 48822E3 88822E3
10 000 35 x 50 5.17 6.31 1.26 40 32 48103E3 88103E3
ELECTRICAL DATA AND ORDERING INFORMATION
U
R
(V)
C
R
100 Hz
(µF)
NOMINAL
CASE SIZE
Ø D x L
(mm)
I
R
100 Hz
105
°C
(A)
I
R
10 kHz
105
°C
(A)
I
L5
5 min
(mA)
MAX. ESR
100 Hz (1)
(m
Ω)
MAX. Z
10 kHz
(m
Ω)
ORDERING
CODE
MAL2158.......
2-TERM. 3-TERM.
