PM75RVA060
Intellimod™ Module
Three Phase + Brake IGBT Inverter Output
75 Amperes/600 Volts
378
Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
Electrical and Mechanical Characteristics, T
j
= 25
°
C unless otherwise specified
Characteristics Symbol Test Conditions Min. Typ. Max. Units
IGBT Inverter Sector
Collector-Emitter Cutoff Current I
CES
V
CE
= V
CES
, V
D
= 15V, T
j
= 25
°
C — — 1.0 mA
V CE = V CES , V D = 15V, T j = 125
°
C — — 10.0 mA
FWDi Forward Voltage V
EC
-I
C
= 75A, V
D
= 15V, V
CIN
= 15V — 2.20 3.30 Volts
Collector-Emitter Saturation Voltage V
CE(sat)
V
D
= 15V, V
CIN
= 0V, I
C
= 75A, — 2.35 2.80 Volts
Pulsed, T
j
= 25
°
C
V
D
= 15V, V
CIN
= 0V, I
C
= 75A, — 2.55 3.05 Volts
Pulsed, T j = 125
°
C
Inductive Load Switching Times t
on
0.4 0.8 2.1 µ S
(Upper-Lower Arm) t
rr
V
D
= 15V, V
CIN
= 0V ~ 15V — 0.2 0.3 µ S
t
C(on)
V
CC
= 300V, I
C
= 75A, — 0.3 1.1
µ
S
t
off
T
j
= 125
°
C — 1.8 2.9
µ
S
t
C(off)
— 0.6 1.2
µ
S
Brake Sector
Collector-Emitter Cutoff Current I
CES
V
CE
= V
CES
, V
D
= 15V, T
j
= 25
°
C — — 1.0 mA
V
CE
= V
CES
, V
D
= 15V, T
j
= 125
°
C — — 10.0 mA
FWDi Forward Voltage V FM I F = 30A — 2.20 3.30 Volts
Collector-Emitter Saturation Voltage V
CE(sat)
V
D
= 15V, V
CIN
= 0V, I
C
= 30A, — 2.35 2.80 Volts
Pulsed, T
j
= 25 ° C
V
D
= 15V, V
CIN
= 0V, I
C
= 30A, — 2.55 3.05 Volts
Pulsed, T
j
= 125
°
C
