C&H Technology CS640525 Tentative - Manual (Page 3)

D-20
Tentative
Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
CS640525
Fast Recovery Single Diode Modules
250 Amperes/500 Volts
Absolute Maximum Ratings
Characteristics Symbol CS640525 Units
Repetitive Peak Reverse Voltage VRRM 500 Volts
Non-Repetitive Peak Reverse Voltage VRSM 600 Volts
DC Reverse Voltage VR(DC) 400 Volts
DC Current, TC = 50°C IDC 250 Amperes
Peak Half-Cycle Surge (Non-Repetitive) On-State Current (60Hz) IFSM 4500 Amperes
I2t (for Fusing), 8.3 milliseconds I2t 8.5 x 104 A2sec
Junction Temperature Tj -40 to 150 °C
Storage Temperature TSTG -40 to 125 °C
Maximum Mounting Torque M5 Mounting Screw — 17 in.-lb.
Maximum Mounting Torque M6 Terminal Screw — 26 in.-lb.
Module Weight (Typical) — 200 Grams
V Isolation VRMS 2500 Volts
Electrical and Thermal Characteristics, Tj = 25°C unless otherwise specified
Characteristics Symbol Test Conditions CS640525 Units
Blocking State Maximums
Repetitive Reverse Current IRRM Tj = 150°C, VRRM = Rated 20 mA
Conducting State Maximums
Forward Voltage Drop VFM IFM = 250A, Tj = 25°C 1.2 Volts
Switching Maximums
Reverse Recovery Time trr IFM = 250A, Tj = 25°C 0.65 ␮ s
di/dt =-200A/ ␮ s, VR = 100V
Reverse Recovery Charge Qrr IFM = 250A, Tj = 25°C 100 ␮ C
di/dt =-200A/ ␮ s, VR =100V
Thermal Maximums
Thermal Resistance, Junction-to-Case R ␪ (J-C)
Per Module 0.2 °C/Watt
Thermal Resistance, Case-to-Fin (Lubricated) R ␪ (C-F)
Per Module 0.08 °C/Watt
Insulation Resistance, Main Terminal-to-Case — Per Module — m
Ω
