Vishay ESTA ESTAdry D-Type Capacitor For Outdoor Use
www.vishay.com Document Number: 13051
6 Revision: 28-Mar-06
ACCESSORIES: SUPPORT FOR POLE AND WALL
MOUNTING
Available types same as for indoor use, different type
designation “F”.
For example:
M12
HEXAGONAL NUT M12
TOOTHED LOCK WASHER
SCREW BOLT M8 x 15
SLOTTED NUT M10
SPRING WASHER WAVE
HEXAGONAL-NUT M10
SCREW BOLT M10
M10
X
2
-
4
4
2
+ 2
-
8
6
2
+
H
±
1
8.
5
1
1
+
X:
172
70
8
7
0
6
1
A
A - A
A
M16
0
0
2
TYPE
RATED VOLTAGE
[V]
RATED OUTPUT
[kvar]
CAPACITANCE
[µF]
CURRENT
[A]
WEIGHT
[kg]
HEIGHT H
[mm]
PhMKDgF 460.3.50 460 50 3 x 250.7 Δ 63 app. 4.9 210
