PM100CSD120
Intellimod™ Module
Three Phase IGBT Inverter Output
100 Amperes/1200 Volts
2
Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
Absolute Maximum Ratings, T
j
= 25°C unless otherwise specified
Characteristics Symbol PM100CSD120 Units
Power Device Junction Temperature T
j
-20 to 150 ° C
Storage Temperature T
stg
-40 to 125 ° C
Case Operating Temperature * T C -20 to 100 ° C
Mounting Torque, M5 Mounting Screws — 31 in-lb
Mounting Torque, M5 Main Terminal Screws — 31 in-lb
Module Weight (Typical) — 920 Grams
Supply Voltage Protected by OC and SC (V
D
= 13.5 - 16.5V, Inverter Part) T
j
= 125 ° C V
CC(prot.)
800 Volts
Isolation Voltage, AC 1 minute, 60Hz Sinusoidal V
ISO
2500 Volts
IGBT Inverter Sector
Collector-Emitter Voltage (V
D
= 15V, V
CIN
= 15V) V
CES
1200 Volts
Collector Current, ± (T C = 25 ° C) I C 100 Amperes
Peak Collector Current, ± (T
C
= 25 ° C) I
CP
200 Amperes
Supply Voltage (Applied between P - N) V
CC
800 Volts
Supply Voltage, Surge (Applied between P - N) V
CC(surge)
1000 Volts
Collector Dissipation (T
C
= 25 ° C) P
C
595 Watts
Control Sector
Supply Voltage Applied between (V UP1 -V UPC , V VP1 -V VPC , V WP1 -V WPC , V N1 -V NC ) V D 20 Volts
Input Voltage Applied between (U P -V UPC , V P -V VPC , W P -V WPC , U N - V N - W N -V NC ) V CIN 20 Volts
Fault Output Supply Voltage (Applied between U
FO
-V
UPC
, V
FO
20 Volts
V
FO
-V
VPC
, W
FO
-V
WPC
, F
O
-V
NC
)
Fault Output Current (U
FO
, V
FO
, W
FO
, F
O
) I
FO
20 mA
Electrical and Mechanical Characteristics, T
j
= 25°C unless otherwise specified
Characteristics Symbol Test Conditions Min. Typ. Max. Units
IGBT Inverter Sector
Collector Cutoff Current I
CES
V
CE
= V
CES
, T
j
= 25 ° C, V
D
= 15V, V
CIN
= 15V — — 1.0 mA
V
CE
= V
CES
, T
j
= 125 ° C, V
D
= 15V, V
CIN
= 15V — — 10 mA
Diode Forward Voltage V
EC
-I
C
= 100A, V
D
= 15V, V
CIN
= 15V — 2.5 3.5 Volts
Collector-Emitter V
CE(sat)
V
D
= 15V, V
CIN
= 0V, I
C
= 100A, Pulsed, T
j
= 25 ° C — 2.4 3.2 Volts
Saturation Voltage V D = 15V, V CIN = 0V, I C = 100A, Pulsed, T j = 125 ° C — 2.1 2.8 Volts
Inductive Load t
on
0.5 1.0 2.5 µ S
Switching Times t
rr
V
D
= 15V, V
CIN
= 0 ~ 15V — 0.15 0.3 µ S
t
C(on)
V
CC
= 600V, I
C
= 100A — 0.4 1.0 µ S
t
off
T
j
= 125 ° C, Inductive Load — 2.5 3.5 µ S
t C(off) — 0.7 1.2 µ S
* T
C
Measure Point
63MM
T
C
10
12
N
V
B
P
W U
3 4 5 6 7 8 9 11
12 14 16 18
13 15 17 19
