RPH 100
Power Resistor for Mounting onto a Heatsink
Thick Film Technology
Vishay Sfernice
GLOBAL PART NUMBER INFORMATION
GLOBAL
MODEL
SIZE LEADS OHMIC VALUE TOLERANCE PACKAGING SPECIAL
RPH 100 F = Faston type
V = M4 screw
The firts four digits are
significant figures and the
last digit specifies the
number of zeros to follow.
R designates decimal point.
48R70 = 48.7
Ω
48701 = 48 700 Ω
10002 = 100 k
Ω
R0100 = 0.01 Ω
R6800 = 0.68
Ω
27000 = 2700 Ω = 2K7 Ω
F = 1 %
G = 2 %
J = 5 %
K = 10 %
B = Box 5 pieces As applicable
Ex = XXX
1 0 0 V 1 0 0 2 B P H R 0 J
