HEXFRED
®
Ultrafast Soft Recovery Diode, 70 A
FEATURES
• Fast recovery time characteristic
• Electrically isolated base plate
• Large creepage distance between terminal
• Simplified mechanical designs, rapid assembly
• Compliant to RoHS Directive 2011/65/EU
• Designed and qualified for industrial level
DESCRIPTION/APPLICATIONS
The dual diode series configuration (HFA70FA120) is used
for output rectification or freewheeling/clamping operation
and high voltage application.
The semiconductor in the SOT-227 package is isolated from
the copper base plate, allowing for common heatsinks and
compact assemblies to be built.
These modules are intended for general applications such
as HV power supplies, electronic welders, motor control and
inverters.
PRODUCT SUMMARY
V
R
1200 V
V
F
(typical)
2.3 V
t
rr
(typical)
51 ns
I
F(AV)
per module at T
C
70 A at 94 °C
SOT-227
ABSOLUTE MAXIMUM RATINGS
PARAMETER
SYMBOL
TEST CONDITIONS
MAX.
UNITS
Cathode to anode voltage
V
R
1200
V
Continuous forward current per leg
I
F
T
C
= 110 °C
35
A
Single pulse forward current per leg
I
FSM
T
J
= 25 °C
380
Maximum power dissipation per module
P
D
T
C
= 110 °C
174
W
RMS isolation voltage
V
ISOL
Any terminal to case, t = 1 min
2500
V
Operating junction and storage
temperature range
T
J
, T
Stg
- 55 to 150
°C
ELECTRICAL SPECIFICATIONS (T
J
= 25 °C unless otherwise specified)
PARAMETER
SYMBOL
TEST CONDITIONS MIN.
TYP.
MAX.
UNITS
Cathode to anode
breakdown voltage
V
BR
I
R
= 100 μA
1200
-
-
V
Forward voltage
V
FM
I
F
= 30 A
-
2.30
3.00
I
F
= 60 A
-
2.89
3.80
I
F
= 30 A, T
J
= 125 °C
-
2.14
2.44
I
F
= 60 A, T
J
= 125 °C
-
2.82
3.27
Reverse leakage current
I
RM
V
R
= V
R
rated
-
1.2
75
μA
T
J
= 125 °C, V
R
= V
R
rated
-
1.0
-
mA
T
J
= 150 °C, V
R
= V
R
rated
-
2.7
10
