RBS8_ _35XX
GENERAL PURPOSE RECTIFIER DIODE
Powerex, Inc.,173 Pavilion Ln, Youngwood, PA 15697-1800 (724)925-7272 www.pwrx.com 3500 Amperes 4200 Volts
Absolute Maximum Ratings
Characteristic Symbol Rating Units
Repetitive Peak Reverse Voltage V
RRM
4200 Volts
Average On-State Current, T
C
=89°C I
F(Avg.)
3500 A
RMS On-State Current, T
C
=89°C I
F(RMS)
5498 A
Average On-State Current, T
C
=55°C I
F(Avg.)
4640 A
RMS On-State Current, T
C
=55°C I
F(RMS)
7288 A
Peak One Cycle Surge Current, 60Hz, V
R
=0.6*V
RRM
I
FSM
65,000 A
Peak One Cycle Surge Current, 60Hz, V
R
=0 I
FSM
81,250 A
Fuse Coordination I 2 t, 50Hz I 2 t 2.75E+07 A 2 s
Peak One Cycle Surge Current, 50Hz, V
R
=0.6*V
RRM
I
FSM
61,905 A
Peak One Cycle Surge Current, 50Hz, V
R
=0V I
FSM
77,381 A
Fuse Coordination I 2 t, 50Hz I 2 t 2.49E+07 A 2 s
Operating Temperature Tj -40 to+150 °C
Storage Temperature T
Stg.
-50 to+200 °C
Approximate Weight 2.5 lb
1.13 Kg
Mounting Force 6,000 - 10,000 lbs
26.6 - 44.4 Knewtons
Information presented is based upon manufacturers testing and projected
capabilities. This information is subject to change without notice. The
manufacturer makes no claim as to suitability for use, reliability, capability or
future availability of this product.
