Document Number: 93895 For technical questions, contact: [email protected] www.vishay.com
Revision: 22-Apr-08 1
High Power Rectifier Diodes
VS24EDR..L Series
Vishay High Power Products
FEATURES
• Standard recovery diode
• Anode metal - nickel plate molybdenum disc
• Rubber passevated junctions
ORDERING INFORMATION TABLE
PRODUCT SUMMARY
Junction size Ø 24 mm
V
RRM
class 1600 to 2500 V
Passivation process Diffused junction
Reference Vishay HPP
packaged part
SD400C..C Series
RoHS
COMPLIANT
MAJOR RATINGS AND CHARACTERISTICS
PARAMETER SYMBOL TEST CONDITIONS VALUES UNITS
Maximum forward voltage V
FM
T
J
= 25 °C, I
F
= 1000 A 1.35
V
Maximum repetitive reverse voltage V
RRM
T
J
= 150 °C, I
RRM
= 15 mA 1600 to 2500
MECHANICAL DATA
Nominal back metal composition Al-Ni-Au
Nominal front metal composition Nickel plate molybdenum disc
Chip dimensions Ø 24 mm (see dimensions - link at the end of datasheet)
Recommended storage environment Storage in original container, in desiccated nitrogen, with no contamination
1 - Vishay HPP device
2 - Chip dimension in millimeters
3
- Type of device: D = Standard recovery diode 4
- Passivation: R = Rubber for all junctions 5
- Voltage code x 100 = V
RRM
6
- Metallization: L = Nickel plate molybdenum disc (anode)
Al-Ni-Au (cathode)
7
Available class
16 = 1600 V
20 = 2000 V
22 = 2200 V
25 = 2500 V
- Device identifier between chip with same diameter
Device code
5 1 3 2 4 6 7
VS 24 E D R 25 L
LINKS TO RELATED DOCUMENTS
Dimensions http://www.vishay.com/doc?95158
