TENTATIVE PP300B060
Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
POW-R-PAK
TM
300A / 600V
H-Bridge IGBT Assembly
PP300B060(-) - 5 -
Performance Curves
Effective Output Current vs. Carrier Frequency (Typical)
Condition Symbol Value Units
Ambient Temperature T
A
40 °C
DC Bus Voltage V
CC
300 Volts
Load Power Factor cos φ 0.8
IGBT Saturation Voltage V
CE(sat)
Typical @ T
J
= 125°C Volts
IGBT Switching Loss E
SW
Typical @ T
J
= 125°C mJ
Airflow - 1500 LFM
Switching Conditions 3 phase PWM, 60Hz sinusoidal output
50
60
70
80
90
100
110
120
130
50 100 150 200 250 300 350
I
out
A
RMS
IG
B
T
J
unc
ti
on T
em
p
er
at
ur
e
10kHz
5kHz
1kHz
