ST1230C..KP Series
Phase Control Thyristors
(Hockey PUK Version), 1745 A
Vishay High Power Products
Note
• The table above shows the increment of thermal resistance R
thJC
when devices operate at different conduction angles than DC
TRIGGERING
PARAMETER SYMBOL TEST CONDITIONS
VALUES
UNITS
TYP. MAX.
Maximum peak gate power P
GM
T
J
= T
J
maximum, t
p
≤ 5 ms
16
W
Maximum average gate power P
G(AV)
T
J
= T
J
maximum, f = 50 Hz, d% = 50 3
Maximum peak positive gate current I
GM
T
J
= T
J
maximum, t
p
≤ 5 ms
3.0 A
Maximum peak positive gate voltage + V
GM
20
V
Maximum peak negative gate voltage - V
GM
5.0
DC gate current required to trigger I
GT
T
J
= - 40 °C
Maximum required gate trigger/
current/voltage are the lowest
value which will trigger all units
12 V anode to cathode applied
200 -
mA T
J
= 25 °C 100 200
T
J
= 125 °C 50 -
DC gate voltage required to trigger V
GT
T
J
= - 40 °C 1.4 -
V T
J
= 25 °C 1.1 3.0
T
J
= 125 °C 0.9 -
DC gate current not to trigger I
GD
T
J
= T
J
maximum
Maximum gate current/
voltage not to trigger is the
maximum value which will not
trigger any unit with rated V
DRM
anode to cathode applied
10 mA
DC gate voltage not to trigger V
GD
0.25 V
THERMAL AND MECHANICAL SPECIFICATIONS
PARAMETER SYMBOL TEST CONDITIONS VALUES UNITS
Maximum operating junction
temperature range
T
J
- 40 to 125
°C
Maximum storage temperature range T
Stg
- 40 to 150
Maximum thermal resistance,
junction to heatsink
R
thJ-hs
DC operation single side cooled 0.042
K/W
DC operation double side cooled 0.021
Maximum thermal resistance,
case to heatsink
R
thC-hs
DC operation single side cooled 0.006
DC operation double side cooled 0.003
Mounting force, ± 10 %
24 500
(2500)
N
(kg)
Approximate weight 425 g
Case style See dimensions - link at the end of datasheet A-24 (K-PUK)
ΔR
thJC
CONDUCTION
CONDUCTION ANGLE
SINUSOIDAL
CONDUCTION
RECTANGULAR
CONDUCTION TEST CONDITIONS UNITS
SINGLE SIDE DOUBLE SIDE SINGLE SIDE DOUBLE SIDE
180° 0.003 0.003 0.002 0.002
T
J
= T
J
maximum K/W
120° 0.004 0.004 0.004 0.004
90° 0.005 0.005 0.005 0.005
60° 0.007 0.007 0.007 0.007
30° 0.012 0.012 0.012 0.012
